BAXIT Replace KNF Micro Diaphragm Gas Pump PM33871-96 Sampling Vacuum Pump
BAXIT Replace KNF Micro Diaphragm Gas Pump PM33871-96 Sampling Vacuum Pump
BAXIT Replace KNF Micro Diaphragm Gas Pump PM33871-96 Sampling Vacuum Pump
BAXIT Replace KNF Micro Diaphragm Gas Pump PM33871-96 Sampling Vacuum Pump
Specifications
Brand Name :
BAXIT
Model Number :
PM33871-96
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
USD258/unit
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
2000units/month
Delivery Time :
1-3 working days
Packaging Details :
Carton box
Model :
PM33871-96
Voltage :
DC24V
Flow rate :
7L/min
Pressure :
2.5bar
Description

BAXIT replace KNF Micro Diaphragm Gas Pump PM33871-96 Sampling Vacuum Pump

Adapt to the environment:

This product is used in industrial process gas continuous analysis system (extraction measurement), for gas extraction, internal anti-corrosion treatment, especially suitable for flue gas analysis. Extraction of gases such as SO2, NOX, CO2, CO, N2, O2, or a mixer can be performed.

BAXIT Replace KNF Micro Diaphragm Gas Pump PM33871-96 Sampling Vacuum Pump

Technical Parameters:

(1) Model:PM33871-96

(2) Flow rate: 7.0L/min

(3) Power supply: DC24V/12V

(4) Interface: 1/8'' internal thread

(5) Piping: Φ6 PTFE tube

(6) Working pressure: Pmax: 2.5 Bar

(7) Weight: 0.6 Kg

Installation method:

This product is panel mounted, the mounting hole spacing is: 48mm, 48mm. The mounting hole size is: 4-Φ5.

Daily maintenance:

This product is an oil-free diaphragm vacuum pump, no need to refuel. If the inside is clogged or contaminated, open the top four screws, clean the gasket, and clean the pump membrane. If there is serious pollution, resulting in air leakage or insufficient air supply during the sampling process, the pump membrane should be replaced in time.

BAXIT Replace KNF Micro Diaphragm Gas Pump PM33871-96 Sampling Vacuum Pump

BAXIT Replace KNF Micro Diaphragm Gas Pump PM33871-96 Sampling Vacuum Pump

BAXIT Replace KNF Micro Diaphragm Gas Pump PM33871-96 Sampling Vacuum Pump
