Refractory Materials Energy Saving Customized Capacity Electric Glass Melting Furnace for Domestic Glass
Refractory Materials Energy Saving Customized Capacity Electric Glass Melting Furnace for Domestic Glass
Refractory Materials Energy Saving Customized Capacity Electric Glass Melting Furnace for Domestic Glass
Refractory Materials Energy Saving Customized Capacity Electric Glass Melting Furnace for Domestic Glass
Refractory Materials Energy Saving Customized Capacity Electric Glass Melting Furnace for Domestic Glass
Refractory Materials Energy Saving Customized Capacity Electric Glass Melting Furnace for Domestic Glass
Specifications
Melting area material :
Electric fused cast AZS
Fuel type :
Electricity
Insulation material :
Clay brick, light clay insulation brick, aluminum silicate
Glass type :
Soda-lime or others
Brand Name :
JEFFER
Model Number :
Customized
Certification :
ISO9001， ISO14001， ISO45001
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T,L/C
Supply Ability :
1 set per 3 months
Delivery Time :
90 days after received the down payemnt
Packaging Details :
Wooden case, tray, steel frame, etc
Material :
Refractory materials
Thermal efficiency :
80%~85%
Description
Refractory ISO45001 Electric Glass Melting Furnace
High Efficient, Electric Heating Glass Furnace, Customized Design

Our electric glass melting furnace represents the pinnacle of modern glass production technology, combining efficiency, precision, and reliability for superior glass manufacturing.

Glass Melting Process Overview

Glass melting is the most critical process in glass production, transforming batched materials into qualified liquid glass through high-temperature heating to achieve uniform composition without bubbles.

Process Stages
  • Glass Liquid Forming: Sinter melts into flint glass liquid with silicate and SiO₂ transformation, though chemical components remain uneven at this stage
  • Clearing: Continuous heating reduces viscosity, releasing gaseous impurities and eliminating visible bubbles
  • Homogenization: Extended high-temperature treatment eliminates ripples through diffusion, creating uniform glass liquid at slightly lower temperatures than clearing stage

This complex process involves physical, chemical, and physicochemical phenomena that transform mechanically mixed raw materials into sophisticated molten glass.

Electric Melting Advantages
  • High thermal efficiency: 80%-85%
  • Significant energy savings
  • Compact footprint
  • Simple structural design
  • Reduced volatilization of expensive oxides
  • Stable melting technology
  • Zero pollution operation
  • Lower noise levels
  • Improved working conditions
  • Homogenized glass liquid quality
  • Superior product quality
  • Automated control systems
  • Reduced maintenance costs
Furnace Structure Components
Melting Tank Primary chamber for glass melting process
Throat Transition area connecting melting and conditioning sections
Forehearth Conditioning section for temperature homogenization
Spout Outlet for controlled glass flow to forming equipment
Refractory Materials Energy Saving Customized Capacity Electric Glass Melting Furnace for Domestic Glass
Melting Section Technology

Our electric furnace utilizes cooling top vertical melting theory to concentrate the melting process. The melting area design optimizes glass melting and homogenization, eliminating dead zones to ensure maximum melting efficiency and superior glass liquid quality.

Construction materials include electric fused cast AZS for melting and non-melting areas, complemented by clay brick, light clay insulation brick, and aluminum silicate products for other structural components.

Refractory Materials Energy Saving Customized Capacity Electric Glass Melting Furnace for Domestic Glass
