2KM SC APC SC UPC G652D 250um Bare Optical Fiber
2KM SC APC SC UPC G652D 250um Bare Optical Fiber
2KM SC APC SC UPC G652D 250um Bare Optical Fiber
2KM SC APC SC UPC G652D 250um Bare Optical Fiber
2KM SC APC SC UPC G652D 250um Bare Optical Fiber
2KM SC APC SC UPC G652D 250um Bare Optical Fiber
2KM SC APC SC UPC G652D 250um Bare Optical Fiber
2KM SC APC SC UPC G652D 250um Bare Optical Fiber
2KM SC APC SC UPC G652D 250um Bare Optical Fiber
2KM SC APC SC UPC G652D 250um Bare Optical Fiber
Specifications
Brand Name :
HICORPWELL
Model Number :
SC-APC/SC-UPC ODTR Launch Cable Spool
Certification :
IEC 60794-2-10/11
Place of Origin :
China
MOQ :
500M
Price :
negotiation
Payment Terms :
Western Union, L/C, T/T
Supply Ability :
1000KM Per Month
Packaging Details :
Standard length: 2km/roll (as per your requirements)
Fiber Type :
G652 bare fiber
Paintcoat Color :
Aqua,yellow ,blue Or Others
Cable Purpose :
SC-APC/SC-UPC ODTR Launch Cable Spool
1310nm :
0.36-0.22 DB/Km
1550nm :
0.5-0.4 DB/Km
Fiber :
G652D,G657A
Certificate :
IEC 60794-2-10/11
Connectors :
Can be added as per your request, SC/LC/FC/ST etc
Description

500m 1KM 2KM 5KM 10KM 20KM 30KM SC-APC/SC-UPC ODTR Launch Cable Spool SM G652D Bare Optical Fiber

An OTDR launch cable, which connects the OTDR to the link-under-test, discloses the insertion loss

and reflectance of the near-end connection.
A fiber ring serves as both a launch cable and a receive cable.

They are also pulse suppressor cables, launch cords, launch leads, receive cables or fiber rings.

OTDR Dummy fiber is designed to be used in conjunction with an OTDR to measure complete link loss of

a fiber. A fiber ring serves as both a launch cable and a receive cable.

  • G652/G657 250um bare fiber
  • Connectors can be added as per your request, SC/LC/FC/ST etc
  • Standard length: 2km/roll (as per your requirements)


Specifications:

Transmission Characteristics

SM
(1310/1550 nm)

50/125
(850/1300 nm)

62.5/125
(850/1300nm)
Max Attenuation (dB/km) 0.4/0.30 3.5/1.5 3.5/1.5
Typical Attenuation (dB/km) 0.35/0.21 3.1/1.0 3.0/1.0
Mini Bandwidth (Mhz.km) -- 400/400 160/500


Note: The OTDR Launch cables can be added with certain connectors, such as FC-FC,SC-SC,FC-SC ST-ST etc.
Please pay attention to the connector type when you order.

Part No.

Description
Fiber-ROLL-SM10

SM G652D, 1KM,
Connector; FC/UPC, SC/UPC, ST/UPC, SC/APC, FC/APC, LC/UPC, LC/APC

optional
Fiber-ROLL-SM20

SM G652D, 2KM,
Connector; FC/UPC, SC/UPC, ST/UPC, SC/APC, FC/APC,
LC/UPC, LC/APC optional
Fiber-ROLL-MM10

MM (62.5/125um or 50/125um), 1KM,
Connector; FC/PC, SC/PC, ST/PC, LC/PC optional
Fiber-ROLL-MM20

MM (62.5/125um or 50/125um), 2KM,
Connector; FC/PC, SC/PC, ST/PC, LC/PC optional
Fiber-ROLL-SM710

SM G657A, 1KM,
Connector; FC/UPC, SC/UPC, ST/UPC, SC/APC, FC/APC, LC/UPC, LC/APC

optional
Fiber-ROLL-SM720

SM G657A, 2KM,
Connector; FC/UPC, SC/UPC, ST/UPC, SC/APC, FC/APC,

LC/UPC, LC/APC optional
Fiber-ROLL-OM310

OM3, 1KM,
Connector; FC/PC, SC/PC, ST/PC, LC/PC optional
Fiber-ROLL-OM320

OM3, 2KM,
Connector; FC/PC, SC/PC, ST/PC, LC/PC optional

2KM SC APC SC UPC G652D 250um Bare Optical Fiber

2KM SC APC SC UPC G652D 250um Bare Optical Fiber2KM SC APC SC UPC G652D 250um Bare Optical Fiber

Glass Bare Fiber Info From Hicorpwell.pdf
