High Quality Aluminum Tilt and Turn Casement Soundproof Window with Multi-Point Locking System
High Quality Aluminum Tilt and Turn Casement Soundproof Window with Multi-Point Locking System
High Quality Aluminum Tilt and Turn Casement Soundproof Window with Multi-Point Locking System
High Quality Aluminum Tilt and Turn Casement Soundproof Window with Multi-Point Locking System
High Quality Aluminum Tilt and Turn Casement Soundproof Window with Multi-Point Locking System
High Quality Aluminum Tilt and Turn Casement Soundproof Window with Multi-Point Locking System
High Quality Aluminum Tilt and Turn Casement Soundproof Window with Multi-Point Locking System
High Quality Aluminum Tilt and Turn Casement Soundproof Window with Multi-Point Locking System
High Quality Aluminum Tilt and Turn Casement Soundproof Window with Multi-Point Locking System
High Quality Aluminum Tilt and Turn Casement Soundproof Window with Multi-Point Locking System
High Quality Aluminum Tilt and Turn Casement Soundproof Window with Multi-Point Locking System
High Quality Aluminum Tilt and Turn Casement Soundproof Window with Multi-Point Locking System
Specifications
Brand Name :
SKATE
Model Number :
SKATE 90 casement window
Certification :
CE,NFRC,AS2047
Place of Origin :
Shandong, China
MOQ :
2 square meters
Price :
$180.00/square meters 2-99 square meters
Payment Terms :
T/T,Western Union,MoneyGram
Supply Ability :
10000000 square meters per month
Delivery Time :
25-45 work days
Packaging Details :
Wooden Case or Iron Frame Packing
Frame Material :
Thermal break aluminum profile
After-sale Service :
Return and Replacement, Online technical support, Onsite Training, Free spare parts
Warranty :
5 years
Frame section width :
90mm
Fan section thickness :
66.7mm
Number of Sealing Layers :
8-way-seal
Insulation strip :
30mm PA66 nylon insulation strip
Locking point lock seat :
Multi-locking point system
Description
Product Description

This 90-degree tilt-and-turn window is made from 6060-T66 aviation-grade aluminum alloy.
The average wall thickness of the profile is 1.8mm, making it stable, corrosion-resistant, and non-deformable.
For thermal insulation, 30mm wide, environmentally friendly PA66 nylon insulation strips are used.
Utilizing advanced cold extrusion technology, it offers high and low temperature resistance and effectively blocks heat and cold transfer.
The entire window frame, sash, center brace, and pressure line are seamlessly welded.
The multi-cavity isothermal structure minimizes indoor air loss and ensures a comfortable indoor temperature.
The hollow aluminum strips are infused with molecular sieves to effectively reduce glass fogging.

Specification
Model 90

Type

 Casement Window

Opening Mode

inswinging casement/outswinging casement/tilt and turn
Air Tightness Level 8
Wind Pressure Resistance Level 9
Water Tightness Level 6

Sound insulation

42dB
Thermal Insulation Performance ≤1.1W/(m2.K)
Glass 5+24A+5 5+9A+5+9A+5
Company Profile
High Quality Aluminum Tilt and Turn Casement Soundproof Window with Multi-Point Locking System
SKATE is one of the first famous doors and Windows brands to enter the home decoration doors and Windows industry in China. It has now developed into a well-known Chinese enterprise mainly engaged in system doors and Windows, sunshine room, smart home, health and other related industries. Since its inception, SKATE adhere to the quality line, the pursuit of excellence, concentrate on the design and research and development of passive high-end doors and Windows, let more families use energy-saving and environmentally friendly passive doors and Windows is the most important corporate responsibility and social mission of SKATE's people. For more than 20 years, SKATE has adhered to its original intention and walked unswervingly till today!
FAQ

Q1:Are you a factory or a trading company?
SKATE Windows: We are a manufacturer which owned 2 factories, one in Beijing and one in Shandong. The total area of our factories is over 100,000m.
Q2: What is your warranty?
SKATE Windows: We offer a 5 year warranty on our products.
Q3: What services you have if windows were damaged?
SKATE Windows: We will replace you the products freely if the issues caused by us.More, we will provide replacement freely if the products is under warranty.
Q4: How can I get your price?
SKATE Windows: Please click the link below to send us an inquiry or contact our sales consultant. We have professional and experienced people to provide you with solutions and prices.


Packing & Delivery
High Quality Aluminum Tilt and Turn Casement Soundproof Window with Multi-Point Locking System
Product Feature

High Quality Aluminum Tilt and Turn Casement Soundproof Window with Multi-Point Locking System

High Quality Aluminum Tilt and Turn Casement Soundproof Window with Multi-Point Locking System
