ASTM B209 5083 Aluminum Coil Aluminum Roll For Transportation
ASTM B209 5083 Aluminum Coil Aluminum Roll For Transportation
ASTM B209 5083 Aluminum Coil Aluminum Roll For Transportation
ASTM B209 5083 Aluminum Coil Aluminum Roll For Transportation
ASTM B209 5083 Aluminum Coil Aluminum Roll For Transportation
ASTM B209 5083 Aluminum Coil Aluminum Roll For Transportation
ASTM B209 5083 Aluminum Coil Aluminum Roll For Transportation
ASTM B209 5083 Aluminum Coil Aluminum Roll For Transportation
Specifications
Brand Name :
JERO
Model Number :
JA90
Certification :
ABS DNV LR KR NK
Place of Origin :
China
MOQ :
7 tons
Price :
3000-3200usd/ton
Payment Terms :
T/T,L/C,Western Union,MoneyGram
Supply Ability :
800 tons per week
Delivery Time :
25-30 working days
Packaging Details :
seaworthy standard export packages
Type :
Aluminum Alloy Coil
Standard :
ASTM B209
Alloy :
5083
Temper :
O/H111/H116
Width :
1000-2900mm
Trade Terms :
FOB/CIF/CFR/EXW
Description


ASTM B209 5083 Aluminum Coil Aluminum Roll Used For Transportation



5083 aluminum sheet belongs to Al-Mg series alloy. It is the highest strength corrosion-resistant

alloy among practical non-heat-treated alloys. And it is suitable for welding structures. Also, it is

worth mentioning that 5083 aluminum sheet has good resistance to seawater and low-temperat

-ure characteristics. Therefore, 5083 aluminum sheet has become the most suitable choice for

marine-grade aluminum.


Mechanical Properties



Temper

Tensile Strength

(MPa)

Yield Strength

(MPa)

Elongation

(%)
O 270-345 125-215 14-18
H111 270-345 125-215 14-18
H116 290-360 215-290 10-14



Key Advantages


♦ Marine-Grade Performance

Saltwater corrosion resistance 3x better than 5052 alloy

Approved for shipbuilding by ABS/DNV/GL classifications

♦ Structural Efficiency

Specific strength comparable to mild steel at 1/3 the weight

Fatigue life 50% longer than 6061-T6 in dynamic loads

♦ Fabrication Benefits

Welding: No preheat required for thicknesses ≤25mm

Forming: Minimum bend radius = 1.5t (H111 temper)


Our Samples in the Workshop:


Alloy/Temper Size (mm) Description
6016-F 8X2608xC 26.5ton the Heaviest Hot-Rolled Coil
6061-F 1.5x1000xC the Thinest Hot-Rolled Coil
3104-H19 0.265x1640xC 3104 Can Body Material Coil
2024-T451 2.0x1850xC 2024 Aluminum Alloy for Aviation Application
5454-H32 8x2800xC 2800mm the Widest Hot-Rolled Coil
3004-H24 0.7x2650xC 2650mm super Wide Cold-Rolled Coil


ASTM B209 5083 Aluminum Coil Aluminum Roll For Transportation



Our company advantages


Technological & Production Strengths:



R&D Capabilities: Own a national-level corporate technology center and contributes to industry

standards.


Production Scale: We had an annual capacity exceeding 0.9 million tons of aluminum large-scale

rolling mills.


Production Ability: We can produce the Aluminum Plate / Coil for automobile, railway transportation,

marine, aerospace etc fields, and obtained the relevant certification.


Our factory own the world advanced equipments, include:


Code Name Brand
A aluminum ignot melting furnace GAUTSCHI (Switzerland)
B 4 continuous hot rolling mills SMS Group (Germany)
C 2800mm width single stand cold rolling mill SMS Group (Germany)
D all automatic three-dimensional elevated warehouse Dematic (USA)


ASTM B209 5083 Aluminum Coil Aluminum Roll For Transportation
