The Construction Platform Slide Wire is an essential component designed specifically for temporary construction elevators, providing reliable and safe operation on construction sites. Engineered to meet the highest safety and durability standards, this wire offers exceptional performance under demanding environmental and mechanical conditions.

Key features include superior flame retardancy rated at V0 level, robust shell protection rating of IP33 (customizable to IP54), and excellent vibration and shock resistance from 10 to 2000 Hz. The wire ensures excellent electrical isolation with insulation resistance exceeding 5 megaohms (>5MΩ) between poles and between poles and ground.

• Product Name: Construction Elevator Slide Wire
• Electrothermal Stability: Imes Rated For 1s
• Net Weight Per Single Rail: 9.25kg
• Configured Quantity of Current Collector: 2 pcs
• Matching Current Collector Model: GHJD-B-80A
• Corrosion Stability: Acid-resistant, Alkali-resistant, Salt Spray Corrosion-resistant
• Suitable for use as Construction Elevator Guide Wire
• Ensures safety as a Construction Lift Safety Wire
• Ideal for Construction Platform Slide Wire applications

The GHEC Construction Elevator Slide Wire (model GHHX-A-25/80A) is designed for demanding construction environments, ensuring safety and efficiency in temporary construction elevators. It supports rated operating voltages from AC 380 to 690 volts and provides a rated peak withstand current of 6.75KA.

Primary applications include high-rise building construction, bridge erection, and large-scale infrastructure projects where reliable vertical transportation of workers and materials is essential.

GHEC offers customized Construction Elevator Slide Wire solutions tailored to specific project requirements. The transmission guide rail complies with GB/T 7251.6 - 2015 standards and supports an incoming copper core cable size of 25mm².

Regular inspection and maintenance are recommended for optimal performance. Installation should be performed by qualified personnel following provided guidelines. Comprehensive technical support is available for installation advice, maintenance procedures, troubleshooting, and replacement parts.

Each slide wire is individually wrapped in protective plastic film and secured in sturdy wooden crates or reinforced cardboard boxes with shock-absorbing materials. Shipping options include road, sea, or air freight via trusted logistics providers with tracking information provided.
