Specifications
Effective Service Length :
3016mm
Model Number :
GHHX-B-12
Place Of Origin :
China
Brand Name :
GHEC
Withstand current :
4.5KA
Transmission guide rail parameters :
Guide Rail Parameters Compliant With GB/T 7251.6 - 2015 Low - Voltage Switchgear And Controlgear - Part 2:<< Particular Requirements For Busbar Trunking Systems (busway)>>
Equivalent Copper Cable Cross-section :
12mm²
Flame retardancy :
Level V0
Number of Poles :
5P
Price :
Interview
Rated peak withstand current :
6.5KA
Acceleration :
49m/S2
Description
Net Weight Per Single Rail 555 Kilograms Sealed Sliding Power Contact

Rated Operating Voltage: AC 380-690V | Durable Electrical Component

Product Overview

The Waterproof Sliding Contact Line is an advanced solution designed to ensure reliable and efficient power transmission in various industrial applications. Engineered for exceptional durability and performance, this product is ideal for environments where water resistance and electrical safety are paramount.

Key Features
  • Product Name: Waterproof Sliding Contact Line
  • Type: Sealed Sliding Power Contact
  • Compatible with GHJD-B-60A current collector model
  • Insulation resistance greater than 5MΩ
  • Flame retardancy: Level V0
  • Waterproof and sealed design
  • Environmental protection: IP33 (customizable to IP54)
Technical Specifications
Configured Quantity of Current Collector 1 piece
Equivalent Copper Cable Cross-section 12mm²
Incoming Cable (Copper Core) 16mm²
Rated Operating Voltage AC 380-690V
Electrothermal Stability 20 times rated current for 1 second
Shell Protection Rating IP33 (customizable to IP54)
Ambient Temperature Range -25℃ to 40℃
Acceleration 49m/s²
Matching Current Collector Model GHJD-B-60A
Applications

The GHEC Waterproof Sliding Contact Line (Model: GHHX-B-12) is widely used in industries such as metallurgy, crane systems, automated production lines, transportation systems, electric railways, and industrial automation. Its waterproof design ensures stable operation in outdoor and semi-outdoor conditions.

Customization Options

GHEC offers customized solutions for the Waterproof Sliding Contact Line with superior vibration and shock resistance (10-2000HZ), flame retardancy rated at Level V0, and support for rated current of 60A at altitudes below 2000 meters.

Support & Services

Regular maintenance is recommended to inspect for wear or damage. Clean sliding surfaces periodically to prevent dirt buildup. Verify alignment and tension for optimal performance. Technical support is available for troubleshooting and expert advice.

Frequently Asked Questions
What is the brand and model number?

Manufactured by GHEC, Model: GHHX-B-12

Where is this product produced?

Made in China

Is it suitable for outdoor use?

Yes, the product is waterproof and designed for outdoor environments

How can I get pricing information?

Please contact the supplier directly for pricing and quotes
