Specifications
Place of Origin :
Zhejiang, China
Brand Name :
Honghuan
Model Number :
MWG
MOQ :
100
Material :
PP
Width :
2-6m
Weight :
100-800g/m2
Length :
50-100m
Tensile Strength MD :
38.5-105.1 kN/m
Tensile Strength CD :
35.9-96.3 kN/m
Elongation MD :
25%
Elongation CD :
25%
Tensile Strength 2% MD :
7-21 kN/m
Tensile Strength 2% CD :
8.6-25 kN/m
Tensile Strength 5% MD :
17.7-52.5 kN/m
Tensile Strength 5% CD :
19.8-53 kN/m
Factory Seam Strength :
18.4-52.5 kN/m
Apparent Opening Size :
0.43-0.6 mm
Permittivity :
0.04-0.9 sec-1
Description

PP Woven Geotextile Fabric 2-6m Width for Separation Filtration

Product Description

Woven Geotextile MWG®

Mono-filament Woven Geotextile, which incorporate round strands that are extruded. It is composed of high-tenacity polypropylene yarns, which are woven into a network such that the yarns retain their relative position. Mono-filament woven geotextile is preferred for applications where both strength and filtration are a concern, such as shoreline rip rap applications.

PP Woven Geotextile Fabric 2-6m Width for Separation FiltrationPP Woven Geotextile Fabric 2-6m Width for Separation FiltrationPP Woven Geotextile Fabric 2-6m Width for Separation Filtration

Product Specifications

PROPERTIES

TEST METHOD

UNIT

MINIMUM AVERAGE VALUE

MWG270

MWG370

MWG570

MWG665

MWG770

Tensile Strength , MD

ASTM D 4595

kN/m

38.5

52.5

70

70

105.1

Tensile Strength , CD

ASTM D 4595

kN/m

35.9

47.3

70

96.3

84

Elongation, MD

ASTM D 4595

%

25

25

25

25

25

Elongation, CD

ASTM D 4595

%

25

25

25

25

25

Tensile Strength at

2%, MD

ASTM D 4595

kN/m

7

11

14

17.5

21

2%, CD

ASTM D 4595

kN/m

8.6

12.3

19.3

25

22.8

5%, MD

ASTM D 4595

kN/m

17.7

21.9

35

35

52.5

5%, CD

ASTM D 4595

kN/m

19.8

22.8

39.4

53

47.1

Factory Seam Strength

ASTM D 4884

kN/m

18.4

25.1

37.5

52.5

43.8

Apparent Opening Size

ASTM D 4751

mm

0.6

0.43

0.6

0.43

0.6

Permittivity

ASTM D 4491

sec-1

0.7

0.9

0.4

0.26

0.04

Water Flow Rate

ASTM D 4491

l/min/m2

2037

1630

1222

815

611

UV Resistance (% retained after 500 hours)

ASTM D 4355

%

80

80

80

70

80

NOTES:

·The values given are Minimum Average Values except elongation and UV resistance. Elongation is a Maximum Value and UV is a typical value.

·Mass per unit area has a tolerance of ±10%.

This information is provided for reference purposes only and is not intended as a warranty or guarantee. Ningbo HongHuan assumes no liability in connection with the use of this information. Specifications subject to change without notice.

PP Woven Geotextile Fabric 2-6m Width for Separation FiltrationPP Woven Geotextile Fabric 2-6m Width for Separation FiltrationPP Woven Geotextile Fabric 2-6m Width for Separation FiltrationPP Woven Geotextile Fabric 2-6m Width for Separation FiltrationPP Woven Geotextile Fabric 2-6m Width for Separation FiltrationPP Woven Geotextile Fabric 2-6m Width for Separation Filtration

Applications

1. Weed block for landscaped garden beds

2. Permeable liners for planters (stops soil erosion)

3. Weed control under wooden decking

4. Geotextile for separating aggregate / soils under walkway blocks or bricks

5. Assists in preventing paving from settling unevenly

6. Landscape fabric prevents soil erosion

more
