Deep diamond core drilling machine 2600m mining drilling equipment
Deep diamond core drilling machine 2600m mining drilling equipment
Specifications
Model Number :
XY-6B
Place of Origin :
CHANGSHA HUNAN
Brand Name :
CHANGTAN
Certification :
SGS/CE/ISO9001
MOQ :
1 SET
Price :
3600USD-10000USD
Packaging Details :
Exported wooden box
Delivery Time :
7-10 working days
Payment Terms :
T/T L/C
Supply Ability :
100 SETS/MONTH
drilling depth :
2600m
drilling diameter :
300mm
NET WEIGHT :
4600kgs (without power)
POWER :
Diesel engine 90KW at 1500 r.p.m
Description

Deep Diamond Core Drilling Machine 2600m Mining Drilling Equipment

XY-6B CORE DRILLING RIG

  • Deep drilling capacity, HQ-1800m, NQ-2400m.
  • Multiple speed grades in forward & reverse revolving, meeting different drilling requirements.
  • Long spindle stroke, higher drilling efficiency.
  • AUTOMOBILE GRADE Clutch and Transmission Box, stable running, lower noise and higher transmission efficiency.
  • Frame sliding retraction, easy to connect and replace drilling tools.
  • Water brake system to the hoist winch, stable delivery when lift or lower drilling tools.

DRILLING CAPACITY Depth 1800m/HQ, 2400m/NQ, 2700m/BQ
SWIVEL HEAD
Type Twin cylinder, Oil-hydraulic feed system, Spindle type
Angle Range 360°
Stroke of Spindle 600mm
Revolving Speed of Spindle Forward 70:120:190:210:320:370:570:980r.p.m
Reverse 45:138 r.p.m
Max. Spindle Torque 8500N*m
Max. Thrust Capacity 150 kN
Max. Balance Capacity 200 kN
Main Clutch AUTOMOBILE GRADE
AVAILABLE RODS 50mm, PQ, HQ, NQ, BQ, AW, BW
FRAME RETRACTION 600mm
HOIST DRUM
Type Planetary grear, hand brake type
Hoisting Capacity 90 kN at single pull line
Rope Speed 0.77:1.33:2.07:3.55:2.35:4.00:6.28:10.77 m/s at single pull time
Drum Capacity Φ21.5mm × 120m
OIL - HYDRAULIC
Type Constant delivery, gear type pump
Delivery Capacity 63L/min @ 2500 r.p.m
Max. Pressure 8MPa
POWER Diesel engine 90KW at 1500 r.p.m
Or electronic Motor, 75KW at 1480 r.p.m
NET WEIGHT 4600kgs (without power)
DIMENSION(L×W×H) 4000 × 1350 ×2300mm
