Specifications
Model Number :
HS-WOVEN
Price :
USD0.8-3.7
Material :
PET (polyester)
Supply Ability :
1000000㎡/month
Geotextile type :
Woven Geotextile
Application :
Building Construction,railway,highway,Road,engineering
Payment Terms :
L/C,T/T
Color :
Customized
Usage :
Construction Project,river bank,Road contruction,slope protection,Package
MOQ :
1000㎡
Delivery Time :
10-20 work days
Function :
Filtration,separation,separation drainage and protection,reinforcement,filter
Place of Origin :
CN
Packaging Details :
PP woven bag
Certification :
ISO
Brand Name :
Haisan
Description

Woven Geotextile Fabric for Truck Mud Road Stabilization

Driving loaded dump trucks over soft, wet ground turns dirt paths into deep mud ruts almost instantly. Our woven geotextile provides a tough, flat plastic grid that lies between the soft dirt and your surface gravel. This tight woven road fabric locks aggregate stones in place, spreading vehicle tire weight across the whole ground surface so trucks can pass safely without sinking or getting stuck.

Technical Specifications

Item
Unit
65x65
150x50
200x50
600x50
1000x50
200x200
Tensile strength
MD
KN/m
65
150
200
600
1000
200
CD
KN/m
65
50
50
50
50
200
Elongation of break
MD
%≤
10
10
11
11
11
11
CD
%≤
10
10
10
10
10
10
Bursting strength
KN/m
3
7.6
10
/
/
20
Equivalent opening size(O95)
mm
0.05-0.5

Why Choose Our Woven Geotextile?

  • Tight Plastic Weave: Interlocked plastic tapes hold their shape under spinning truck tires, keeping stones from shifting sideways.

  • Stops Gravel Waste: Keeps expensive stone base layers sitting cleanly on top of the fabric instead of disappearing into the mud below.

  • Rolls Out Straight by Hand: Two workers can easily unroll the fabric directly onto the dirt floor and trim it with a utility knife.

  • Pure Polymer Filament: Made from clear polypropylene plastic that will not rot, mold, or break down when left in wet dirt.

Primary Applications

  • Construction Haul Roads: Unrolled over soft dirt to create a solid temporary lane for loaded concrete trucks and excavators.

  • Farm Access Tracks: Placed under gravel paths to keep tractor wheels from spinning and cutting deep mud grooves in farm fields.

  • Logging Truck Routes: Laying a firm base across swampy forest ground for heavy timber transport trucks.

  • Gravel Staging Yards: Spread under gravel storage pads to stop heavy shipping containers from tilting on soft soil.

Frequently Asked Questions (FAQ)

Q1: Does this Filament Woven Geotextile stretch much under heavy truck loads?

A:No, unlike nonwoven Geotextile, this stabilization Geotextile features a highly rigid, low-elongation weave designed to engage instantly and stop soil movement with minimal stretching

Q2: Which country did you export?

A: Our products have been exported to more than 20 countries all over the world, including USA, Canada, Poland, Switzerland, Japan, Southeast Asia, The Middle East, Africa, Australia etc.

Q3: What is your MOQ?

A: Normally, our MOQ is 20' container. But we could accept LCL for first trial order.
