Specifications
Packaging Details :
PP Woven Bag
Geotextile type :
Non-Woven Geotextiles
Supply Ability :
1000000㎡ per month
Elongation at break :
40%-80%,
Model Number :
hs-nonwoven
Keyword :
Nonwoven Needle Punched Geotextile,Non woven fabric,Polyester/PP non woven geotextile,Pet Nonwoven Fabric,High Quality Geotextile For Road
MOQ :
1000㎡
Place of Origin :
CN
Weight :
100-800g
Usage :
Ecological Slope Protection System,construction project,dam,etc,civil environmental
Fiber type :
staple fiber,polyester continuous filament,long fiber
Brand Name :
Haisan
Certification :
ISO
Application :
Building Construction,dam,Reinforcement,civil construction,engineering
Price :
USD 0.2-3.5
Package :
PP Woven Bags,Customerised
Payment Terms :
L/C,T/T
Delivery Time :
5-10 work days
Material :
PP(polypropylene) PET (polyester)
Description
High-Modulus Polyester Continuous Filament Long Fiber Geotextile For Subgrade Stabilization

Our Filament Non-woven Geotextile is engineered utilizing a high-precision, direct-spinning thermal process where first-grade polyester chips are converted into unbroken, continuous micro-strands. This infinite fiber network is then densely needle-punched, creating a fabric with an extraordinarily high tensile modulus and exceptional multi-directional puncture resistance. Unlike staple fibers, the unbroken filament matrix ensures the material absorbs tremendous physical impact and lateral movement without stretching or tearing. It serves as an elite-level hydraulic separator and reinforcing base, preventing different soil horizons from intermixing while allowing massive water volumes to pass through smoothly under heavy structural loads.

High-Modulus Polyester Continuous Filament Long Fiber Geotextile For Subgrade Stabilization

High-Modulus Polyester Continuous Filament Long Fiber Geotextile For Subgrade Stabilization

Technical Specifications
Specification
100
150
200
300
400
500
600
800
Remark
Quality deviation per unit acreage%
-6
-6
-6
-5
-5
-4
-4
-4

Thickness,mm≥
0.8
1.2
1.6
2.2
2.8
3.4
4.2
5.5

Width deviation for range,%m
-0.5

Mightiness at break,KN/m ≥
4.5
7.5
10.0
15.0
20.5
25.0
30.0
40.0
Vertical and horizontal
Elongation at break,%
40-80
CBR bursting strength,KN≥
0.8
1.4
1.8
2.6
3.5
4.7
5.5
7.0

Effective aperture O90(O95)mm
0.07-0.20

Vertical osmotic coefficient,cm/s
K x(10-1-10-3)
K=1.0-9.9
Tearing strength, KN≥
0.14
0.21
0.28
0.42
0.56
0.70
0.82
1.10
Vertical and horizontal
Why Choose Our Geomembranes?
  • Unbroken Fiber Strength: Our advanced direct-spinning setup ensures infinite thread length per roll, delivering up to 30% higher grab tensile strength than standard recycled alternatives.
  • Zero-Thin-Spot Consistency: Every square meter undergoes continuous mechanical density-monitoring, guaranteeing completely uniform filtration and thickness across the entire project area.
  • Instant WhatsApp & Email Tech Support: Got questions about which specification fits your project? Message or email us anytime for quick, direct tech answers and product selection advice.
  • Remote Installation Layout Assistance: Send us your basic site dimensions via email or chat, and our team will quickly calculate the ideal roll layout to help you minimize overlap waste.

High-Modulus Polyester Continuous Filament Long Fiber Geotextile For Subgrade Stabilization

Primary Applications
  • Airport Runways: Installed beneath heavy-load concrete runways to distribute wheel impact and prevent subgrade pumping.
  • Coastal Armor Layering: Placed under breakwater rip-rap or concrete blocks to stop the sea from washing away underlying sand.
  • High-Speed Rail Tracks: Reinforcing the ballast foundation to absorb constant high-frequency vibration and prevent track deformation.
  • Tunnel Linings: Serving as a thick, untearable water-conveying and protective cushion between the rough rock wall and the waterproofing liner.
  • Landfill Caps: Providing a robust, puncture-proof barrier that guards critical containment membranes against sharp gravel damage.

High-Modulus Polyester Continuous Filament Long Fiber Geotextile For Subgrade Stabilization

Frequently Asked Questions (FAQ)

Q1: Are you manufacturer or trading company?

A: We are manufacturer.

Q2: Which country did you export?

A: Our products have been exported to more than 20 countries all over the world, including USA, Canada, Poland, Switzerland, Japan, Southeast Asia, The Middle East, Africa, Australia etc.

Q3: What is your MOQ?

A: Normally, our MOQ is 20' container. But we could accept LCL for first trial order.
