6kw High Quality Diesel Generator Portable Customizable 220V 380v With Wheels And Handrails
6kw High Quality Diesel Generator Portable Customizable 220V 380v With Wheels And Handrails
6kw High Quality Diesel Generator Portable Customizable 220V 380v With Wheels And Handrails
6kw High Quality Diesel Generator Portable Customizable 220V 380v With Wheels And Handrails
6kw High Quality Diesel Generator Portable Customizable 220V 380v With Wheels And Handrails
6kw High Quality Diesel Generator Portable Customizable 220V 380v With Wheels And Handrails
6kw High Quality Diesel Generator Portable Customizable 220V 380v With Wheels And Handrails
6kw High Quality Diesel Generator Portable Customizable 220V 380v With Wheels And Handrails
6kw High Quality Diesel Generator Portable Customizable 220V 380v With Wheels And Handrails
6kw High Quality Diesel Generator Portable Customizable 220V 380v With Wheels And Handrails
Specifications
Brand Name :
JIWEI
Model Number :
JW-YMT
Certification :
ce
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Rated voltage :
110V/220V/230V/380V/400V/440V,120 to 440V
Frequency :
50/60HZ
Speed :
3600rpm,3000/3600RPM
Rated current :
5A-30A
Rated power :
6kw
Output type :
AC Single Phase,DC,AC 3 Phase,Other
Color :
customizable
Engine type :
Air-cooled diesel Engine,ECU
Starting system :
Manual start, remote start, electric start
Function :
Provide Electric Power
Fuel tank capacity :
10-25L，According To Customers' Requirement
Alternator type :
Brush alternator with AVR or brushless with AVR,Three phase alternator
Product :
6kw High Quality Diesel Generator Portable Customizable 220V 380v With Wheels And Handrails
Description

6kw High Quality Diesel Generator Portable Customizable 220V 380v With Wheels And Handrails


Overview


Core Advantages of 3-10kW Small Diesel Generators

• Good Economy: Low fuel consumption and low long-term operating costs.

• Durable and Reliable: Simple structure, low failure rate, and long service life.

• Strong Load Adaptability: Capable of short-term overload and compatible with equipment with high starting current.

• Flexible Application Scenarios: Portable or fixed installation, suitable for emergency power supply, outdoor construction, etc.

• Easy Fuel Storage: Low volatility, high ignition point, safe and long-term storage.


Specification

Model CA7800XE CA10000EXE
Rated frequency(Hz) 50 50
Rated voltage (V) 230/400 230/400
Rated power(KW) Single phase 5.5 Three phase 6.0 Single phase 6.4 Three phase 7.2
Number of phases Single phase/Three phase/Equal power Single phase/Three phase/Equal power
Size(mm) 750×515×640 750×515×640
Net weight(kg) 119 126
Fuel tank capacity(L) 12.5/16 12.516
Noise(decibels @7m) 85 85
Engine model 188FE 192FE
type Straight,single cylinder,air-cooled,four stroke
Cylinder diameter(mm) 88 92
Piston stroke(mm) 75 75
Displacement(ml) 456 498
Fuel consumption rate g/kw*h ≤275 ≤277
Rated speed (r/min) 3000 3000
Starting system 12Vstarter motor 12V starter motor
Insulation Class H H
Continuous working time(h) 8 8
Fuel grade Diesel:0"(summer),-10"(winter)
Oil grade SAE 10W30 (CD grade or above)
Optional configuration ATS/remote control/digital control panel/wheels and handles


Picetures

6kw High Quality Diesel Generator Portable Customizable 220V 380v With Wheels And Handrails

6kw High Quality Diesel Generator Portable Customizable 220V 380v With Wheels And Handrails

6kw High Quality Diesel Generator Portable Customizable 220V 380v With Wheels And Handrails

6kw High Quality Diesel Generator Portable Customizable 220V 380v With Wheels And Handrails

6kw High Quality Diesel Generator Portable Customizable 220V 380v With Wheels And Handrails

6kw High Quality Diesel Generator Portable Customizable 220V 380v With Wheels And Handrails

6kw High Quality Diesel Generator Portable Customizable 220V 380v With Wheels And Handrails

6kw High Quality Diesel Generator Portable Customizable 220V 380v With Wheels And Handrails


FAQ


1.Q: What is your MOQ of this item?
A:1 Sets.

2.Q: What is the lead time?
A:7 working days after received the 30%T/T deposit.
3.Q: Is it all right to make customer's own brand name?
A:We can be your OEM manufacture with your authorization of brand.
4.Q: Where is your Loading Port?
A:Shanghai or others.
5.Q: What are your payment terms?
A:30% TT as deposit,70% TT before Shipment.
6.Q: What is your company's available production capacity?
A:100 Sets per month.
7.Q:What's the warranty time of diesel generators?
A:12 months or 1000 working hours, whichever comes first.
