Wall Mounted 5KW 15.36KWh Energy Storage System 143kWh for Household Solar Power for Wholesale and OEM Use
Wall Mounted 5KW 15.36KWh Energy Storage System 143kWh for Household Solar Power for Wholesale and OEM Use
Wall Mounted 5KW 15.36KWh Energy Storage System 143kWh for Household Solar Power for Wholesale and OEM Use
Wall Mounted 5KW 15.36KWh Energy Storage System 143kWh for Household Solar Power for Wholesale and OEM Use
Specifications
Brand Name :
Solarose
Model Number :
5kw power
Certification :
CE, RoHS, IEC 62619 Battery Safety Standard
Place of Origin :
Guangdong,China
MOQ :
10
Price :
us$1850 per unit
Payment Terms :
T/T, L/C
Supply Ability :
1000PCS Per week
Delivery Time :
25 days
Packaging Details :
In a one pack
Product Type :
Integrated All - in - One Solar Generator
Power Capacity :
5KW Inverter Power, 15.36KWh Battery Capacity
Charge Parameters :
Charge Voltage: 58.4V, Charge Current: 100A, Max Charge Current: 100A
Inverter Details :
Output Voltage: 230Vac±5%, Frequency: 50Hz/60Hz, Input Power (PV): 5KW, Input Voltage Range (PV): 120 - 450Vdc
Safety Features :
Overcharge Protection, Overdischarge Protection, Overcurrent Protection
Application Scenarios :
Overcharge Protection, Overdischarge Protection, Overcurrent Protection
Battery Specifications :
51.2V Battery Voltage, 300Ah Battery Capacity
Communication Features :
RS485/CAN Communication, RJ45 Connect Port, WIFI Enabled
Discharge parameter :
Discharge Current: 100A, Max Discharge Current: 110A, Max Peak Current: 150A, Discharge Cut - off Voltage: 43.2V
Description

5KW 15.36KWh Integrated All - In - One Solar Generator Powered By Solar

Product description:

This 5KW 15.36KWh Integrated All - in - One Solar Generator is a reliable and efficient renewable energy solution. Powered by solar, it features a 5KW inverter that can handle multiple devices simultaneously. The 15.36KWh battery, with 51.2V and 300Ah, ensures long - term power supply. It can sutable many application scenarios.
With a 100A charge current and a wide 120 - 450Vdc PV input range, it can quickly recharge and is compatible with various solar panels. RS485/CAN, RJ45, and WIFI enable easy remote monitoring. Plus, multiple safety protections like overcharge and overdischarge safeguard the system, making it ideal for homes, off - grid areas, and small businesses.


Technical parameter:
Inverter Power Continuous 5KW
Battery Capacity 15.36KWh, 51.2V, 300Ah
Charge Voltage 58.4V
Charge Current Normal 100A, Max 100A
Discharge Current Normal 100A, Max 110A, Max Peak 150A
Discharge Cut - off Voltage 43.2V
Input Voltage Range (PV) 120 - 450Vdc
Output Voltage (AC) 230Vac±5%
Frequency 50Hz/60Hz
Communication RS485/CAN, RJ45 Port, WIFI
Installation Type Wall - mounted
Operating Temperature Range -20°C - 50°C

Feature Advantages:

  • 5KW High - Power Inverter, Powers Multiple Devices Simultaneously
  • 15.36KWh Ultra - large Battery, Long - lasting Off - grid Power Supply
  • 300Ah High - Capacity Cell, Stable Performance in Harsh Conditions
  • 100A Rapid Charging, Reduces Battery Recharge Time Significantly
  • Wide PV Input Range (120 - 450Vdc), Compatible with Various Solar Panels
  • RS485/CAN & WIFI Integration, Enables Remote Monitoring and Control
  • Military - Grade Safety Features, Protects Against Overcharge and Overdischarge
  • Wall - Mounted Plug - and - Play Design, Easy Installation and Space - savingCan this solar generator work with a smart home system?
