TAKUMI R5B12-77 Spark Plug Spark Plugs match for 243-4291 for Denso GI3-1 Champion FB77WPC C-U-M-M-I-N-S Q19G
TAKUMI R5B12-77 Spark Plug Spark Plugs match for 243-4291 for Denso GI3-1 Champion FB77WPC C-U-M-M-I-N-S Q19G
TAKUMI R5B12-77 Spark Plug Spark Plugs match for 243-4291 for Denso GI3-1 Champion FB77WPC C-U-M-M-I-N-S Q19G
TAKUMI R5B12-77 Spark Plug Spark Plugs match for 243-4291 for Denso GI3-1 Champion FB77WPC C-U-M-M-I-N-S Q19G
TAKUMI R5B12-77 Spark Plug Spark Plugs match for 243-4291 for Denso GI3-1 Champion FB77WPC C-U-M-M-I-N-S Q19G
TAKUMI R5B12-77 Spark Plug Spark Plugs match for 243-4291 for Denso GI3-1 Champion FB77WPC C-U-M-M-I-N-S Q19G
Specifications
Brand Name :
TAKUMI
Model Number :
R5B12-77C
Certifiion :
TS16949 ISO9001
Place of Origin :
Hunan,China
MOQ :
20
Price :
By discussed
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
10000 pieces per month
Delivery Time :
30 working days
Packaging Details :
Tin, Plastic box, white box, Carton,As cunstomer request
Description

TAKUMI R5B12-77 Spark Plug Spark Plugs match for 243-4291 for Denso GI3-1 Champion FB77WPC C-U-M-M-I-N-S Q19G

Reliability is built, not claimed. Our production and QC teams work together to deliver spark plugs that perform consistently in the harshest conditions.

Product Overview

TAKUMI R5B12-77 spark plug is a form, fit and function equivalent replacement for OEM part 243-4291. TAKUMI R5B12-77 iridium industrial spark plug, cross-referenced to Champion RB77WPCC / Denso GI3-1 / Altronic L1863B family.

Every TAKUMI unit is produced in an ISO 9001 and IATF 16949 certified factory, 100% tested before shipment. The plug is engineered for long service life in continuous operation, with a nickel-plated shell, copper-core electrode and high-grade ceramic insulator.

Key Specifications

  • TAKUMI TypeR5B12-77
  • Thread SizeM18 x 1.5
  • Reach20.6 mm (13/16")
  • Hex Size22.2 mm (7/8")
  • Seat TypeFlat
  • Spark Gap0.3 mm
  • Heat Range77
  • Electrode TypeIridium / Double J
  • ResistorYes

Cross Reference

  • ChampionRB77WPCC / KB77WPCC / RB77CC / PB78WPC / RB77WPC
  • DENSOGI3-1 / GI3-3 / GI3-5
  • ALTRONICL1863B / L1863IP / L1863DP
  • Federal Mogul / BERU18GZ4-77 / 18GZ6-77-2
  • C-A-T243-4291 / 301-6663 / 194-8518
  • WAUKESHA60999Z / 69919D / 69919Z
  • C-U-M-M-I-N-S4098162
  • GUASCOR7664292

Applications

  • CAT G3500 series (G3508 / G3512 / G3516 / G3520)
  • WAUKESHA gas engines
  • C-U-M-M-I-N-S Q19G
  • Industrial gas generators

Advantages

  • Drop-in replacement - no engine parameter changes required
  • Reliable ignition under high pressure and lean combustion
  • Anti-corrosion nickel-plated housing
  • 95% alumina insulator for heat and shock resistance
  • Monolithic resistor for stable conductivity
  • Factory direct with competitive pricing and short lead time

OE numbers are for reference only. Final fitment should be confirmed before ordering.

Factory & Quality Control

TAKUMI R5B12-77 Spark Plug Spark Plugs match for 243-4291 for Denso GI3-1 Champion FB77WPC C-U-M-M-I-N-S Q19G

Our QC team records batch numbers for full traceability. Should any issue arise, we can quickly isolate the production batch and respond within 48 hours.

Production Workshop

TAKUMI runs a fully integrated manufacturing base: CNC machining, automated assembly and 100% functional testing under one roof.

TAKUMI R5B12-77 Spark Plug Spark Plugs match for 243-4291 for Denso GI3-1 Champion FB77WPC C-U-M-M-I-N-S Q19GTAKUMI R5B12-77 Spark Plug Spark Plugs match for 243-4291 for Denso GI3-1 Champion FB77WPC C-U-M-M-I-N-S Q19GTAKUMI R5B12-77 Spark Plug Spark Plugs match for 243-4291 for Denso GI3-1 Champion FB77WPC C-U-M-M-I-N-S Q19G

From raw material to finished spark plug, every process is controlled in-house with ISO-certified procedures.
