Mechanical Shock Tester with 500～155000N Shock Range 20 to 1500G Peak Acceleration and 10KG Max Load for Battery Testing Lab
Mechanical Shock Tester with 500～155000N Shock Range 20 to 1500G Peak Acceleration and 10KG Max Load for Battery Testing Lab
Mechanical Shock Tester with 500～155000N Shock Range 20 to 1500G Peak Acceleration and 10KG Max Load for Battery Testing Lab
Mechanical Shock Tester with 500～155000N Shock Range 20 to 1500G Peak Acceleration and 10KG Max Load for Battery Testing Lab
Specifications
Pulse duration :
0.2~18ms
Power required :
AC 220V±10％ 50Hz，2kVA
Shock Range(N): :
500～155000
Payment Terms :
L/C,D/P,T/T,Western Union,MoneyGram
MOQ :
1 set
Operating platform :
250 × 200 mm
Equipment dimensions :
660 × 700 × 1900mm
Brand Name :
Gelon
Model Number :
GN-SKT-10
Certification :
ce
Place of Origin :
china
MOQ :
1 set
Price :
2300~8900usd/pcs
Supply Ability :
500pcs/month
Delivery Time :
25 working days
Packaging Details :
Standard exported package : Internal anticollision protection, external export wooden box packaging.
Equipment weight :
820 kg
Max. load :
10KG
Peak acceleration :
20 to 1500G
Product Name :
Mechanical Shock Tester
Description
Battery Equipment Mechanical Shock Tester - Shock Testing System for Battery Testing Labs
Product Overview

The BE-SKT series shock testing systems are designed for comprehensive shock resistance testing across multiple industries including electronics, aerospace, shipping, automotive components, and transportation. These systems support various shock waveforms including half sine wave, final peak saw tooth wave, and trapezoidal wave tests through selectable waveform generators.

Standards Compliance

This shock testing system complies with major international standards including IEC62133, UL1642, UN38.3, and other national and international standards such as: GB/T2423-2008, GJB150, GJB360, GJB548, UN38.3, IEC-62281, GJB1217, MIL-STD-202F, IEC-68-2-27, MIL-STD-810F, and MIL-STD-883E.

Key Features
  • Free drop type shock tester utilizing hydraulic lifting and high-pressure fluid braking
  • Pneumatic-hydraulic boosting with strong friction brake to prevent secondary shock braking
  • Advanced shock measurement device with single-channel data acquisition, simultaneous acceleration data measurement, storage, report printing, data callback, and database management for two channels
  • Rubber module technology producing wide range of half sine pulses with arbitrary action time
  • Capable of equivalent drop testing for packing boxes
Technical Specifications
Input Channels 2 channels
Sampling Frequency 192KHz
Pulse Duration 50-1ms
Communication Interface USB2.0
Supported Standards ISO, UN38.3, MIL-STD-810, user defined
Product Images
Mechanical Shock Tester with 500～155000N Shock Range 20 to 1500G Peak Acceleration and 10KG Max Load for Battery Testing Lab
Mechanical Shock Tester with 500～155000N Shock Range 20 to 1500G Peak Acceleration and 10KG Max Load for Battery Testing Lab
Mechanical Shock Tester with 500～155000N Shock Range 20 to 1500G Peak Acceleration and 10KG Max Load for Battery Testing Lab
Mechanical Shock Tester with 500～155000N Shock Range 20 to 1500G Peak Acceleration and 10KG Max Load for Battery Testing Lab
Mechanical Shock Tester with 500～155000N Shock Range 20 to 1500G Peak Acceleration and 10KG Max Load for Battery Testing Lab
Mechanical Shock Tester with 500～155000N Shock Range 20 to 1500G Peak Acceleration and 10KG Max Load for Battery Testing Lab
