0° Spiral Bevel Gear for Intersecting Axis Transmission with Low Noise and Stable Power Delivery
0° Spiral Bevel Gear for Intersecting Axis Transmission with Low Noise and Stable Power Delivery
Specifications
Brand Name :
DINGSCO
Model Number :
According to customers' requests
Certification :
ISO 9001
Place of Origin :
Changsha, China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
Negotiable
Delivery Time :
(Sample order) 7 days
Packaging Details :
According to customers' requests
Material :
20CrMnTi, 40Cr, 42CrMo, Stainless Steel
Shape :
Bevel Gear
Teeth Profile :
Gleason
Heat Treatment :
Carburization and quenching/Carbonitriding/High frequency/Quenched and tempered......
Teeth Accuracy Grade :
ISO 4-6 Grade
Mounting :
Spline or Threaded Shaft End
Description
0° Spiral Bevel Gear: Elevate Industrial Transmission with Precision & Durability
The 0° spiral bevel gear (also known as Zerol bevel gear) combines the structural advantages of straight bevel gears and spiral bevel gears. Engineered for intersecting axis transmission (typically 90°), it delivers balanced performance, easy interchangeability, and reliable operation across diverse industrial scenarios. Below is a comprehensive breakdown of its core characteristics, manufacturing standards, performance advantages, and application fields.

0° Helical Gear Manufacturing Process
  • Material Choice: Commonly uses alloy steels such as 20CrMnTi and 42CrMo for strength and toughness.
  • Heat Treatment: Carburizing, quenching, and tempering ensure a balance of surface hardness and core toughness.
  • Tooth Finishing: CNC grinding guarantees precise tooth geometry and consistent meshing.
  • Quality Control: Rigorous inspection with CMMs and gear measuring instruments ensures dimensional and functional accuracy.

0° Helical Gear Application Fields
  • Automotive & Transportation: Motorcycle transmissions, automotive transfer cases, and high-speed rail auxiliary systems, leveraging low noise and stable power delivery.
  • Industrial Machinery: Machine tools (feed boxes), reducers, parking systems, and textile machinery, adapting to medium-speed (≤5m/s) and high-precision requirements.
  • Aerospace & Defense: Aircraft auxiliary transmissions, balancing lightweight design and high-load resistance.
  • Medical & High-Tech: Medical equipment, semiconductor manufacturing equipment, and solar energy systems, where precision and low vibration are critical.
  • Agricultural & Construction Machinery: Tractor steering systems and small engineering machinery, withstanding harsh working conditions and requiring minimal maintenance.
Procurement Advantages
  • Cost Control: Manufactured with high-quality alloy steel and advanced processes, ensuring durability while keeping costs competitive.
  • Mass Supply Capability: Supports both small trial orders and large-scale long-term supply.
  • On-Time Delivery: Efficient production planning and inventory management guarantee timely delivery.
  • Customization Options: Modules, teeth numbers, bore sizes, and surface treatments can be tailored to requirements.
  • Consistent Quality: Each gear undergoes hardness, dimensional, and dynamic balance testing.

Structural Features

    • Tooth Contact Mode: Adopts local (point) contact design, which avoids edge contact and eccentric loads common in straight bevel gears.
    • Force Consistency: Bears the same load as straight bevel gears, enabling direct interchangeability without modifying the existing support system or bearing structure.
    • Dimensional Versatility: Available in modules ranging from m0.5 to m15, with outer diameters spanning 20mm to 1000mm, adaptable to both standard and custom specifications.
Material 20CrMnTi, 40Cr, 42CrMo, Stainless Steel
Shape Spiral / Helical gear
Teeth Profile Gleason
Module (M) ≤4
Accuracy Grade ISO 4-6 Grade
Service Customized
Processing Forging, hobbing, shaping, shaving, grinding etc.
Hardness HRC 58-62 (after carburizing & quenching)

Why Choose Us?
  • Professional engineering team to ensure precision and quality
  • OEM/ODM services available to meet diverse application needs
  • Strict inspection process to guarantee stable performance
