40000N.m Double Speed Travel Reducer With Two Ratio
40000N.m Double Speed Travel Reducer With Two Ratio
40000N.m Double Speed Travel Reducer With Two Ratio
40000N.m Double Speed Travel Reducer With Two Ratio
Specifications
Brand Name :
Deren
Model Number :
GFT040T3B24-140
Certification :
ISO9001
Place of Origin :
China
MOQ :
1pc
Price :
USD5000
Supply Ability :
500pcs per month
Delivery Time :
30 days
Packaging Details :
Plywood case with pallet
Series :
GFT
Max. output torque :
40000 Nm
Application :
Track drive
Weight :
150 kg
First ratio :
24:1
Second ratio :
140:1
Description

40000N.m Planetary Reducer for Track Drive and Wheel Hub.

With two ratio for Double speed.

GFT series Travel Drives are the ideal driving components for wheel or track driving vehicles and other mobile equipment. They are the perfect choice for every conceivable moving or turning application. The drives are extremely compact and thus may also be installed in space-critical mounting configurations. Based on the using of case-hardened annulus gears, the load capacity and availability of these Drives are extraordinary.

Features:

With two ratio options for double speed in one drive

Compact structure and space-saving design

Robust main bearing system

Integrated static multiple disk parking brake

Optional Disconnect device for towing

Optional Quick disconnection device

Simple mounting

Easy oil change

Low-noise running operation

Specifications:

Model GFT040T3B
Max. output torque: 40000 N.m
Rated output torque: 2000 N.m
Ratio:

24 and 140
Dynamic Loading: 708 KN
Static Loading: 355 KN
Motor connection: Rexroth, Danfoss, Electric
Application: Travel for Track, Chain and Wheel driving machines

Deren Transmission is a professional manufacture of various power drive components. Our experienced technical team will bring you strong support in finding ideal parts for your machines and projects.
