OK-SP4060-MG Magnetic Pin Flexible Board Support Fully Automatic Solder Paste Printer

The OK-SP4060-MG features an innovative magnetic pin flexible board support system that eliminates the need for dedicated tooling plates, vacuum blocks, or custom fixtures. Operators can configure board support in seconds by placing magnetic pins and support blocks anywhere on the grid — enabling sub-3-minute changeover between different PCB designs in high-mix SMT production.

Key Features

• Magnetic Pin Grid Array: Steel grid plate with 10mm pitch accepts magnetic-based support pins anywhere on the surface — no screws, clamps, or dedicated fixtures required
• Tooling-Free Changeover: Layout magnetic pins on the grid according to PCB bottom-side component clearance and store the configuration photo for repeat setups
• 50 Magnetic Pins Plus 10 Support Blocks: Comprehensive kit included with pins covering 5mm-50mm height range and support blocks for large empty areas
• Dual-Side Access: Both sides of the grid are accessible with magnetic pins, allowing support for complex double-sided assembly PCBs
• Reduced Tooling Cost: Eliminates the need to fabricate custom support plates for each PCB design — typical savings of 200-500 USD per unique PCB design
• Vibration Damping: Magnetic retention combined with rubber-tipped pins provides inherent vibration damping for high-speed squeegee travel

Technical Specifications

Applications

Optimized for EMS providers and contract manufacturers running high-mix, low-to-medium volume production with frequent product changeovers. Significantly reduces line downtime and tooling fabrication costs compared to dedicated support plate systems.

Packaging and Shipping

Standard export wooden crate with dedicated magnetic pin storage case. Factory calibration report included. Delivery in 7-15 working days.
