Specifications
Model Number :
BLB1500
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
140-175USD
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
10000pcs/month
Delivery Time :
2-8 work days
Packaging Details :
34*28*40cm
Color :
Black
Maximum Door Weight :
1500KG
Rated Power :
300W
Door Speed :
7-15m/min
Input Voltage :
110V/220V
Output Voltage :
DC24V
Power Lithium Battery :
5Ah/10Ah Built-in
Description
Adjustable Speed Low Voltage Brushless Sliding Gate Opener
BLB1000/1500/2000 DC24V Motor with Speed Potentiometer - Professional grade sliding gate opener systems designed for residential, commercial, and industrial applications.
Key Features
Adjustable Motor Speed

Easily adjust operating speed (7-15 m/min) via built-in speed potentiometer. Clockwise rotation increases speed, counter-clockwise decreases speed. Flexible control suits different door weights and application scenarios.

  • All-Around Electric Limit Switch: Single-stroke learning cycle permanently memorizes limit positions. No relearning required after power failure or manual movement.
  • Soft Start and Soft Stop: Smooth acceleration and deceleration with adjustable deceleration distance (10-80 cm) and speed. Reduces mechanical wear for long-term reliability.
  • Obstacle Reversal Protection: Automatically detects obstacles during operation with audible alerts and automatic reversal for enhanced safety.
  • Automatic Closing Function: Adjustable delay time (1-250 seconds) for automatic closure after opening - ideal for contactless operation requirements.
  • Abundant External Interfaces: Compatible with infrared sensors, license plate recognition, access control systems, alarm lights, solar panels, and backup batteries.
  • Low-Voltage DC 24V Operation: Safe low-voltage operation with AC 220V input. Ensures personal safety during installation and maintenance.
  • High Durability and Protection: IP65 weatherproof rating, operating temperature -30℃ to +70℃, noise level <53 dB, brushless motor for longer service life.
  • Multiple Built-in Protections: Motor overcurrent, overload, short circuit, motor failure, and reverse power supply protection.
  • Easy Installation and Commissioning: Clear wiring diagrams, manual clutch release, and simple remote control pairing for quick setup.
Technical Specifications
Parameter BLB-1000 BLB-1500 BLB-2000
Max Gate Weight 1000 kg 1500 kg 2000 kg
Max Travel Limit 1-10 m 1-10 m 1-10 m
Rated Power 200W 300W 400W
Speed 7-15 m/min (Adjustable) 7-15 m/min (Adjustable) 7-15 m/min (Adjustable)
Input Voltage AC220V±10% AC220V±10% AC220V±10%
Working Temp -30℃ ~ +70℃ -30℃ ~ +70℃ -30℃ ~ +70℃
Protection Class IP65 IP65 IP65
Noise <53 dB <53 dB <53 dB
Product Image
