Vertical Steam Boiler For Fast Steam Output And Convenient Transportation
Vertical Steam Boiler For Fast Steam Output And Convenient Transportation
Vertical Steam Boiler For Fast Steam Output And Convenient Transportation
Vertical Steam Boiler For Fast Steam Output And Convenient Transportation
Vertical Steam Boiler For Fast Steam Output And Convenient Transportation
Vertical Steam Boiler For Fast Steam Output And Convenient Transportation
Vertical Steam Boiler For Fast Steam Output And Convenient Transportation
Vertical Steam Boiler For Fast Steam Output And Convenient Transportation
Specifications
Brand Name :
taiguo boiler
Model Number :
LHS
Certification :
CE,SGS,EAC
Place of Origin :
HENAN,CHINA
MOQ :
1
Price :
1699-3200USD
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
100set
Delivery Time :
20-30days
Packaging Details :
nude packing
Drum Placement :
Vertical Boiler
Fuel Type :
Gas/Oil
Size :
Compact
Advantage :
High heating efficiency
Evaporation Capacity :
0.2t/h
Efficiency :
95%
Flue Type :
Direct/Indirect
Water Circulation :
Natural Circulation
Thermostat Included :
Yes
Manufacturing Level :
A
Rated steam pressure :
0.7-1.0(Mpa）
Description

product presentation

Steam generators are mechanical devices that use the heat energy of fuels or other energy sources to heat water into hot water or steam. Steam generators are divided into electric heating steam generators, oil steam generators, gas steam generators and biomass steam generators. Mainly used in: industrial factories, hotels, restaurants, food processing, chemical industry, institutions, schools, hospitals, enterprises and institutions, swimming pool, temporary construction, villa and family heating and sauna bath, steam, hot water, heating, cooking, disinfection, drying heating and other fields.

product feature

  • Fast steam output
  • The steam generator can produce steam in a short time, usually within 5 minutes, short working time, and high thermal efficiency of the product.
  • Small size
  • The steam generator is small, convenient for transportation and installation, and does not take up too much space.
  • easy to use
  • Steam generator is a small steam boiler product, its water capacity is small, usually not more than 30 liters, no need to carry out record inspection when in use, product use without certification.
  • safe and reliable
  • The steam generator has multiple protection devices, such as leakage protection system, water shortage protection device, automatic power off function, and high safety factor.
Technical Paramet


Model

Rated
Capacity
(t/h)

Rated
Pressure
(Mpa)

Rated
Temperature
(C)

Maximum
transport weight
of boiler(t)


Maximum transport size of boiler( mm)
Fuel Consumption

diesel oil (Kg/h)

Natural
gas (m³/h)

LPG (kg/h)
LHS0.05
0.05

0.4

151
0.37
700× 650×1700
8.2
10.2
6.45
LHS0.1
0.1
0.59
800×750 ×2000
11.3
13.6
13
LHS0.2
0.2



0.4~0.7



151~170
0.68
900× 850×2000
15.6
18.7
19.4
LHS0.3
0.3
0.83
1000×950×2000
22.5
26.8
25.6

LHS0.5

0.5

1.07

1100×1050×2000

32.5

36.8

32

LHS0.7

0.7





0.4~0.7





151~170

1.45

1200×1150×2200

40.6

48.5

50

LHS1

1

1.78

1300×1250×2450

45.9

65.3

65

LHS1.5
1.5

1.9

1780×1600×3200

78.4

102.1

97

LHS2

2

5.2

2000×2000×4000

91.8

130.6

130
Note: 1,Fuel type:Light diesel oil/Heavy oil/Natural gas/Liquefied gas/City gas
2 ,Parameter is for reference only, we can design the boilers based on customers’ needs.
Applications: textile factory, food and beverage, chemical industry, light industry, rubber, printing and dyeing factory, paper factory, wood process-ing, clothing,laundry, etc.
Vertical Steam Boiler For Fast Steam Output And Convenient Transportation
Vertical Steam Boiler For Fast Steam Output And Convenient Transportation
FAQ

Q1:How can you get the best price quickly?

1.We need to know the boiler capacity, the fuel you plan to use and the steam pressure you need, and then we can confirm the boiler model.
2. Customer needs to provide us your name, email address and company name, and then we will send you price list immediately.And if you use whatsapp, skype or wechat, you can provide us your ID, it will be more convenientfor our communication.

Q2:Why choose us?

1.40+ years of boiler manufacturing experience, 10 years of export experience.A grade boiler factory.
2.Free replacement of parts for one year, lifetime maintenance of the main engine, except for improper operation.

Q3:What is the using life of your boiler?

Electric control cabinet adopts PLC touch screen, display in English. It shows working condition details of boiler, such as water temperature, water pressure, exhaust gas temperature, and over-pressure alarm, etc. In addition, the cabinet is used for set up the parameter, record and analyze the operation data, etc.

Q4:What is the using life of your boiler?

Normally the boiler is designed for 20 years life span, but with right operation and good maintenance,the boiler can be used for 20-25 years.
