Product introduction:

CWNS series automatic oil (gas) horizontal hot water boiler (utility model patent), the use of horizontal three-return wet back structure, improve the boiler operating environment, improve boiler efficiency and service life; All flue gas channels are placed in water, the tail is equipped with waste heat water tank and perfect insulation outsourcing design, and the smoke box seal adopts labyrinth structure to avoid the smoke box leakage phenomenon. The thermal efficiency of the boiler is as high as 90~97%, and the combination of corrugated furnace and conical furnace with good expansion performance is adopted. The furnace furnace size is consistent with the flame, and the flue gas flow area is reduced to make the flue gas flow at the same speed, ensuring the heat exchange time of high temperature flue gas in the furnace, and achieving the best heat transfer effect. The high performance burner that is fully matched with the boiler is fully automatic adjusted to make the combustion full, save fuel and reduce pollution. The use of ultra-fine glass wool with high thermal insulation performance, less heat loss; The intelligent energy-saving control system is used to control the boiler and water supply, heating and automatic water temperature system, and adjust the fuel supply combined with different loads to save energy.

Product characteristics:

1. Horizontal internal combustion three return full wet back design, 100% corrugated furnace, with good thermal scalability, water cooled recombustion chamber, recombustion chamber and the rear tube plate edge butt, the lowest stress, more reliable quality.
2. The explosion-proof device connected with the furnace is provided on the boiler back plate to prevent the fuel from violent deexplosion in the furnace, release the high energy of the moment, and can automatically reset, and has the function of fire viewing mirror and inspection channel, using the adjustment of the combustion flame in operation, furnace inspection and easy maintenance.
3. The smoke box adopts double open smoke box door, easy to open, multi-level labyrinth seal, special sealing material, good compression performance, completely prevent the leakage of smoke, and can be reused.

Technical parameter:

Product display:

Q1: How can you get the best price quickly?
1.We need to know the boiler capacity, the fuel you plan to use and the steam pressure you need, and then we can confirm the boiler model.
2. Customer needs to provide us your name, email address and company name, and then we will send you price list immediately.And if you use whatsapp, skype or wechat, you can provide us your ID, it will be more convenient for our communication.

Q2:Why choose us?
1.40+ years of boiler manufacturing experience, 10 years of export experience.A grade boiler factory.
2.Free replacement of parts for one year, lifetime maintenance of the main engine, except for improper operation.

Q3: Details of electric control cabinet
Electric control cabinet adopts PLC touch screen, display in English. It shows working condition details of boiler, such as water temperature, water pressure, exhaust gas temperature, and over-pressure alarm, etc. In addition, the cabinet is used for set up the parameter, record and analyze the operation data, etc.
Q4:What is the using life of your boiler?
1.Normally the boiler is designed for 20 years life span, but with right operation and good maintenance,the boiler can be used for 20-25 years.
