Customization Length Not Perforated U Shaped Galvanized Channel Metal For Building Construction
Customization Length Not Perforated U Shaped Galvanized Channel Metal For Building Construction
Customization Length Not Perforated U Shaped Galvanized Channel Metal For Building Construction
Customization Length Not Perforated U Shaped Galvanized Channel Metal For Building Construction
Specifications
Place of Origin :
Hebei, China
Certification :
ISO9001
MOQ :
Negotiable
Price :
Negotiable
Packaging Details :
According to customer needs
Delivery Time :
15-30 work days
Payment Terms :
TT
Perforated Or Not :
Not Perforated
Application :
Construction, Machinery, Shipbuilding, Etc.
Thickness :
1.5mm-5.0mm
Name :
U-shaped Channel Steel
Material :
Galvanized Steel
Usage :
Building Construction Materials
Length :
Customization
Processing services :
Include Bending, Welding, Punching, Uncoiling, And Cutting
Steel grade :
Q235
Description

Product Description:

This Galvanized Channel Metal is available in a variety of thicknesses, ranging from 1.5mm to 5.0mm, making it suitable for a wide range of applications. Its length is customizable, which means that it can be cut to fit the specific needs of your project. The shape of this product is a channel, which is a type of structural steel that has a C-shaped cross-section. The channel shape makes it ideal for supporting heavy loads and providing additional strength to structures.

This Galvanized Metal U-Channel is not perforated, which means that it does not have any holes or openings in it. This is important for applications where a solid and continuous surface is required. For example, this product can be used as support beams, braces, and other load-bearing structures. The lack of perforations also makes it easier to install and work with, as there are no sharp edges or corners that could cause injury or damage to equipment.

The material used to make this Galvanized Channel Steel is high-quality galvanized steel. Galvanized steel is a type of steel that has been coated with a layer of zinc, which provides additional protection against corrosion and rust. This makes it ideal for outdoor applications where the product will be exposed to the elements. The galvanization process also improves the overall strength and durability of the steel, making it suitable for use in heavy-duty applications.

Technical Parameters:

Length Customization
Name U-shaped Channel Steel
Perforated Or Not Not Perforated
Application Construction, Machinery, Shipbuilding, Etc.
Shape Channel
Surface Treatment Zinc Plated Steel Channel
Material Galvanized Steel
Thickness 1.5mm-5.0mm
Technique Hot Rolled Steel Channel
Usage Building Construction Materials

Specifications
Height
Width
Thickness
5#
50
37
4.5
6.3#
63
40
4.8
8#
80
43
5.0
10#
100
48
5.3
12#
120
53
5.5
14#a
140
58
6.0
14#b
140
60
8
16#a
160
63
6.5
16#b
160
65
8.5
18#a
180
68
7
18#b
180
70
9
20#a
200
73
7
20#b
200
75
9
22#a
220
77
7
22#b
220
79
9
25#a
250
78
7
25#b
250
80
9
25#c
250
82
11
28#a
280
82
7.5
28#b
280
84
9.5
28#c
280
86
11
30#a
300
85
7.5
30#b
300
87
