Specifications
Brand Name :
GNEE
Certification :
ISO9001,SGS
MOQ :
10 square meter
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
100 ton/week
Delivery Time :
5-9 working days
Packaging Details :
Sea-worthy packing, ie wooden or steel tray with steel strip,etc
Description

Product Description

APPLICATION OF STEEL GRATING:

1. Water treatment: repair walkway, trench cover board, large container, cleaning device, blocking grate, running water tank, biochemical water treatment pool pendant, ventilation window, stairs, cooling tower operation table paving surface.
2. Chemical plant: stairway board, operating platform, guardrail, double floor, trench cover board, filter grate oil
3. Industry: offshore oil platforms
4. Textile mill: replace metal grille, wooden platform and cover cement ground, next to the dye tank, floor, near the valve, etc..
5. Power plant: chemical water workshop trench cover plate, waste pool, etc..
6. Marine food processing plant: slippery surface and other harsh environment, ships.
7. Transport: platforms, ship decks, walkways, stairs.
8. Beverage industry: Staircase floor board, replacement of expensive stainless steel, loaded floor.

Heavy-Duty Galvanized Steel Grating for Safe Stair Treads Grating Fence for Security

Item Description
Bearing Bar 25x3, 25x4, 25x4.5, 25x5, 30x3, 30x4, 30x4.5, 30x5, 32x5, 40x5,

50x5, 65x5, 75x6, 75x10,100x10mm etc;

I bar: 25x5x3, 30x5x3, 32x5x3, 40x5x3 etc.

US standard: 1'x3/16', 1 1/4'x3/16', 1 1/2'x3/16',

1'x1/4', 1 1/4'x1/4', 1 1/2'x1/4', 1'x1/8', 1 1/4'x1/8',

1 1/2'x1/8' etc.
Bearing Bar Pitch 12.5, 15, 20, 25, 30, 32, 35, 38, 40, 60, 80mm etc.

US standard: 19-w-4, 15-w-4, 11-w-4, 19-w-2, 15-w-2 etc.

Noted:19-W-4 is most popular(19/16 inch x 4 inch opening=30x100mm opening)
Twisted Cross Bar Pitch 50, 60, 76, 100, 120mm etc.

US standard: 2' & 4' etc.
Surface Treatment Black, self colour, hot dip galvanized, painted, spray coating
Grating Style Plain / Smooth, Serrated /teeth, I bar, serrated I bar

Packaging & Shipping
