Specifications
Brand Name :
GNEE
Certification :
SGS
Place of Origin :
China
Price :
Negotiable
Payment Terms :
Negotiable
Supply Ability :
100 ton/week
Delivery Time :
5-9 working days
Packaging Details :
Sea-worthy packing, ie wooden or steel tray with steel strip,etc
Description

Perforated Metal Sheet is one of the most versatile and stylish metal protects in our life, has various hole sizes, high strength-to-weight ratio, good ventilation and light penetration. It is a metal plate with various shapes of holes on the surface.Product applications are widely used in various industries such as pharmaceutical equipment, food and beverage machinery, harvesting machines, dry cleaning machines,sound elimination equipment, refrigeration equipment (central air conditioning) speakers, and filtering equipment.

304 316 Stainless Steel Perforated Round Hole Mesh Sheet Punching Metal Mesh

Hole Diameter Staggered Centers Sheet Thickness Open Area
0.045" 1.14mm 0.066" 0.033-0.039" 0.84-0.99mm 0.37
1/16" 1.59mm 3/32" 0.027-0.033" 0.68-0.84mm 0.41
1/16" 1.59mm 1/8" 0.027-0.066" 0.68-1.69mm 0.23
5/64" 1.98mm 1/8" 0.027-0.053" 0.68-1.35mm 0.35
0.081" 2.06mm 1/8" 0.053-0.066" 1.35-1.68mm 0.38
3/32" 2.38mm 5/32" 0.053-0.066" 1.35-1.68mm 0.33
1/8" 3.17mm 3/16" 0.027-0.127" 0.68-3.23mm 0.4
5/32" 3.97mm 3/16" 0.027-0.066" 0.68-1.68mm 0.63
3/16" 4.76mm ¼" 0.027-0.127" 0.68-3.23mm 0.5
1/4" 6.35mm 3/8" 0.033-0.111",0.25" 0.84-2.82mm,6.35mm 0.4
3/8" 9.52mm ½" 0.053-0.082",3/16" 1.35-2.08mm,4.76mm 0.51
3/8" 9.52mm 9/16" 0.059",0.119" 1.50mm,3.02mm 0.4
1/2" 12.70mm 11/16" 0.033-0.127",3/16" 0.84-3.23mm,4.76mm 0.48
1/4" Hex 6.35mm Hex 0.285 0.027-0.033 0.68-0.84mm 0.76
3/8" Sq. 9.52mm Sq. Cane 0.053-0.066" 1.35-1.68mm 0.51

304 316 Stainless Steel Perforated Round Hole Mesh Sheet Punching Metal Mesh

Product Name Perforated Metal Mesh
Material Stainless Steel, Low carbon Steel,Aluminum,Galvanized Steel,Copper, Brass, etc
Hole Patterns Straight rows, staggered and arbitrary patterns
Thickness 0.5-10mm
0.5-10mm round,rectangular, square, hexagonal,diamond ,triangular, irregular hole
Size
sheets: 1m×2m ,1.2m×2.4m ,1.22m×2.44m etc other size can be customized
rolls: 1m×20m,1.2m×20m,1.5m×20m etc other size can be customized
Margin Types with or without margins
