China Supplier Diamond Hole Flattened Expanded Metal Mesh Factory
China Supplier Diamond Hole Flattened Expanded Metal Mesh Factory
China Supplier Diamond Hole Flattened Expanded Metal Mesh Factory
China Supplier Diamond Hole Flattened Expanded Metal Mesh Factory
China Supplier Diamond Hole Flattened Expanded Metal Mesh Factory
China Supplier Diamond Hole Flattened Expanded Metal Mesh Factory
China Supplier Diamond Hole Flattened Expanded Metal Mesh Factory
China Supplier Diamond Hole Flattened Expanded Metal Mesh Factory
Specifications
Brand Name :
GNEE
Certification :
ISO9001,SGS
Place of Origin :
China
MOQ :
10 square meter
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
100 ton/week
Delivery Time :
5-9 working days
Packaging Details :
Sea-worthy packing, ie wooden or steel tray with steel strip,etc
Description

Product Description

Expanded metal mesh is also called pulled plate wire mesh. A rigid piece of metal that has been slit and drawn into an open mesh pattern in a single operation. It is stronger, lighter in weight and more rigid than the original base metal.

Expanded metal mesh material are carbon steel plate, stainless steel, galvanized steel, aluminum, aluminum foil, lead, nickel plate, titanium, aluminum-magnesium alloy panels. Conventional mesh is formed in a diamond pattern. It has other pattern of hexagonal, round, triangle, scale-like opening.

China Supplier Diamond Hole Flattened Expanded Metal Mesh Factory

Features and benefits of expanded metal mesh:

Higher strength-to-weight ratio than sheet metal
Anti-slip surface
Excludes and retains simultaneously
Premium reinforcement properties
Practical and effective screening
Super corrosion resistance
Expanded metal mesh has a wide range of uses, graceful shapes, strong processing capability. A major advantage of expanded is that the mesh is formed from a single piece of material

Thickness(mm) SWD(mm) LWD(mm) Strand(mm) Width(m) Length(m) Weight(kg/m 2 )
0.5 2.5 4.5 0.5 0.5 1 1.8
0.5 10 25 0.5 0.6 2 0.73
0.6 10 25 1 0.6 2 1
0.8 10 25 1 0.6 2 1.25
1 10 25 1.1 0.6 2 1.77
1 15 40 1.5 2 4 1.85
1.2 10 25 1.1 2 4 2.21
1.2 15 40 1.5 2 4 2.3
1.5 15 40 1.5 1.8 4 2.77
1.5 23 60 2.6 2 3.6 2.77
2 18 50 2.1 2 4 3.69
2 22 60 2.6 2 4 3.69
3 40 80 3.8 2 4 5.00
4 50 100 4 2 2 11.15
4.5 50 100 5 2 2.7 11.15
5 50 100 5 1.4 2.6 12.39
6 50 100 6 2 2.5 17.35
8 50 100 8 2 2.1 28.26

China Supplier Diamond Hole Flattened Expanded Metal Mesh Factory
