Specifications
Brand Name :
GNEE
Certification :
SGS
Place of Origin :
China
MOQ :
10 square meter
Price :
Negotiable
Description

Product Introduction

THE POPULAR SPECIFICATIONS OF STEEL GRATING

The grating with a pitch of 30mm between bearing bars is the most widely used type in the industrial field. Among normal types, it has the strongest resistance to surface lash.

The grating with a pitch of 40mm between bearing bars is the most economical and lightest type. lt is the best choice for you on occasions when the span is small.

The grating with a pitch of 60mm between the bearing bars and a pitch of 50mm between the cross bars is developed especially for the mining industry, it solved the problem of a mineral splash on the plate. So it is often appointed for use in processing works of the mining industry.

The grating with a pitch of 30mm between bearing bars and of76mm between cross bars is the most popular type used at home and abroad, it is proper for many applications such as walkways, platforms, etc.

Bearing Bar Spacing 1– 1/4

STAINLESS STEEL GRATING - 304 & 316 MATERIALS FOR CORROSIVE PROJECTS

Stainless steel grating is regarded as industrial-grade bar grating, which is extremely strong, durable, and corrosive resistant for all load-bearing applications and is primarily used for pedestrian and light vehicle traffic.

- Both in Smooth or serrated surface.
- 304 or 316 grade for choice.
- Wide range of bearing bar sizes and pitches.
- Special discount for large orders.
- Project references can be supplied for your bid.
- ISO Certificated factory.
- CAD or 3D drawings can be supplied for your design and construction.

Bearing Bar Spacing 1– 1/4

Stainless Steel Grade Load/Deflection Multiply Carbon Steel Load Tables By: Based on Maximum Allowable Fiber Stress
304Stainless Steel U 1.111 20,000 P.S.I. (137.9 MPa)
C 1.111
D 1.151
304LStainless Steel U 0.917 16,500 P.S.I. (113.8 MPa)
C 0.917
D 0.949
316Stainless Steel U 1.111 20,000 P.S.I. (137.9 MPa)
C 1.111
D 1.151
316LStainless Steel U 0.917 16,500 P.S.I. (113.8 MPa)
C 0.917
D 0.949
