Specifications
Brand Name :
Gnee
MOQ :
2PCS
Supply Ability :
300000 Square Meter/Square Meters per Month
Delivery Time :
Shipped in 20 days after payment
Packaging Details :
Fix with metal belt Packing with pallet ,outside wrap with waterproof plastic film Finial in container
Description

Steel bar grating with high strength and firm structure is made up of carbon steel, aluminum steel, or stainless steel. According to the manufacturing methods, it can be divided into four types: welded, press-locked, swage-locked, and riveted gratings. According to the surface shapes, it can be divided into smooth and serrated gratings. With various styles and sizes for choice, steel gratings are widely used in everyday life, such as stair treads, walkways, platforms, floors, various covers, wheeled equipment, security screens, heavy-duty constructions, and so on.


The grating with a pitch of 30mm between bearing bars is the most widely used type in the industrial field. Among normal types, it has the strongest resistance to surface lash.
The grating with a pitch of 40mm between bearing bars is the most economical and lightest type. lt is the best choice for you on occasions when the span is small.
The grating with a pitch of 60mm between the bearing bars and a pitch of 50mm between the cross bars is developed especially for the mining industry, it solved the problem of a mineral splash on the plate. So it is often appointed for use in processing works of the mining industry.
The grating with a pitch of 30mm between bearing bars and of76mm between cross bars is the most popular type used at home and abroad, it is proper for many applications such as walkways, platforms, etc.


Technical specifications of our stainless steel bar grating are shown in the table below:

Specification Description
Material 304, 304L, 316, 316L stainless steel
Manufacturing Process Welded, swage-locked, or press-locked
Surface Type Standard plain surface, serrated surface
Cross Bar Spacing 2" or 4", center to center
Bearing Bar Spacing 15/16" or 1-3/16", center to center
Bearing Bar Height 20mm to 60mm
Bearing Bar Thickness 2mm to 5mm
Cross Bar Size 4mm to 10mm diameter
Slip Resistance Serrated or plain surface, depending on the application
Installation Method Welding, clips, or bolts and nuts, depending on the application
Compliance Meets industry standards and applicable building codes, including ASTM, ISO, and ANSI/NAAMM

Note:
For more information on safe load data, please feel free to contact us, and our engineers will be more than happy to share them with you.
