Precision Seamless Steel Pipe, BS 3059-2
Precision Seamless Steel Pipe, BS 3059-2
Precision Seamless Steel Pipe, BS 3059-2
Precision Seamless Steel Pipe, BS 3059-2
Precision Seamless Steel Pipe, BS 3059-2
Precision Seamless Steel Pipe, BS 3059-2
Precision Seamless Steel Pipe, BS 3059-2
Precision Seamless Steel Pipe, BS 3059-2
Precision Seamless Steel Pipe, BS 3059-2
Precision Seamless Steel Pipe, BS 3059-2
Specifications
Place of Origin :
Jiangsu, China (Mainland)
Brand Name :
YH
Model Number :
API
MOQ :
50 Ton/Tons
Packaging Details :
In bundle ,seaworthy standard export packing ,plastic caps
Delivery Time :
Within 25 days
Payment Terms :
L/C   T/T   30% T/T in advance and balance by L/C at sight
Supply Ability :
1000 Ton/Tons for Month
Description

Precision Seamless Steel Pipe, BS 3059-2

Specifications

seamless steel pipe

1,Cr5Mo, 12CrMo, Cr2Mo

2, precision

3, machinery industry, oil cylinder


Description:

1.1.1 Specifications

1.Grade: 10#, 20#, 45#, 15CrMo, Cr5Mo, 12CrMo, Cr2Mo
2.Standard: BS 3059-2, GB 3087-1999, GB/T 3094-2000, GB/T 8713, GB/T3639, DIN 2391, ASTM A106-2006,

ASTM A179-1990
3.Outer diameter: 8 - 95 mm
4.Thickness: 0.5 - 14 mm
5.Cert:API

Application:

mainly used in automobile industry, machinery industry, oil cylinder, automobile shock absorber.

Product Name:

Precision seamless steel pipe

Product

Outer Diameter:8-95mm
Thickness:0.5-14mm
Legth:Not by size or on demand

application: mainly used in automobile industry, machinery industry, oil cylinder, automobile shock absorber.

Description Specification

1: Precision seamless steel pipe is a high-precision steel pipe through a cold drawn or hot rolling process,due to

this tube inside and outside wall without oxide layer, withstand high pressure and without leakage, high-precision,

high-quality finish, cold-formed without deformation,bellig, flattening cracks etc. Therefore, the products are mainly

used in the production of pneumatic or hydraulic components such as the cylinder or cylinder.

Product Feature

1: Small outer diameter

2:Due to the high precision so it can be short run production

3:The cold drawn products with high precision and surface is better

4: Steel pipe cross area more complex

5: Superior performance of steel pipe, the metal is more dense

Specification

Φ4×0.5

Φ16×0.5

Φ26×1.8

Φ35×9.0

Φ4×0.8

Φ16×0.8

Φ26×2.0

Φ35×10

Φ4×1.0

Φ16×1.0

Φ26×2.2

Φ38×0.5

Φ4×1.2

Φ16×1.2

Φ26×2.5

Φ38×0.8

Φ5×0.5

Φ16×1.5

Φ26×2.8

Φ38×1.0

Φ5×0.8

Φ16×1.8

Φ26×3.0

Φ38×1.2

Φ48×5.0

Φ70×2.8

Φ90×10

Φ130×14

Φ48×5.5

Φ70×3.0

Φ90×12

Φ130×16

Φ48×6.0

Φ70×3.5

Φ90×14

Φ130×18

Φ48×7.0

Φ70×4.0

Φ90×16

Φ140×2.5

Φ48×8.0

Φ70×4.5

Φ95×2.0

Φ140×2.8

Φ48×9.0

Φ70×5.0

Φ95×2.2

Φ140×3.0

Precision steel tube size tolerance

Dimensional tolerances (wall thickness deviation ± 5%)

The size of the diameter

H8

H9

H10

30

+0.0330

+0.0520

+0.0840

30-50

+0.0390

+0.0620

+0.1000

50-80

+0.0460

+0.0740

+0.1200

80-120

+0.0540

+0.0870

+0.1400

120-180

+0.0630

+0.1000

+0.1600

180-250

+0.0720

+0.1150

+0.1850

250-315

+0.0810

+0.1300

+0.2100

315-400

+0.0890

+0.1400

+0.2300
