15CrMo, Cr5Mo Precision Seamless Rectangular Steel Pipe For Automobile Industry, Oil Cylinder
15CrMo, Cr5Mo Precision Seamless Rectangular Steel Pipe For Automobile Industry, Oil Cylinder
15CrMo, Cr5Mo Precision Seamless Rectangular Steel Pipe For Automobile Industry, Oil Cylinder
15CrMo, Cr5Mo Precision Seamless Rectangular Steel Pipe For Automobile Industry, Oil Cylinder
15CrMo, Cr5Mo Precision Seamless Rectangular Steel Pipe For Automobile Industry, Oil Cylinder
15CrMo, Cr5Mo Precision Seamless Rectangular Steel Pipe For Automobile Industry, Oil Cylinder
15CrMo, Cr5Mo Precision Seamless Rectangular Steel Pipe For Automobile Industry, Oil Cylinder
15CrMo, Cr5Mo Precision Seamless Rectangular Steel Pipe For Automobile Industry, Oil Cylinder
15CrMo, Cr5Mo Precision Seamless Rectangular Steel Pipe For Automobile Industry, Oil Cylinder
15CrMo, Cr5Mo Precision Seamless Rectangular Steel Pipe For Automobile Industry, Oil Cylinder
15CrMo, Cr5Mo Precision Seamless Rectangular Steel Pipe For Automobile Industry, Oil Cylinder
15CrMo, Cr5Mo Precision Seamless Rectangular Steel Pipe For Automobile Industry, Oil Cylinder
Specifications
Place of Origin :
Jiangsu, China (Mainland)
Brand Name :
YH
Certification :
API
MOQ :
50 Ton/Tons
Packaging Details :
In bundle ,seaworthy standard export packing ,plastic caps
Delivery Time :
Within 25 days
Payment Terms :
L/C   T/T   30% T/T in advance and balance by L/C at sight
Supply Ability :
100  Ton/Tons / Week
Description

15CrMo, Cr5Mo Precision Seamless Rectangular Steel Pipe For Automobile Industry, Oil Cylinder

Description:

1.1.1 Specifications

1.Grade: 10#, 20#, 45#, 15CrMo, Cr5Mo, 12CrMo, Cr2Mo
2.Standard: BS, GB, DIN, ASTM
3.Outer diameter: 8 - 95 mm
4.Thickness: 0.5 - 14 mm
5.Cert:API

Precision seamless steel pipe

Product

Outer Diameter:8-95mm
Thickness:0.5-14mm
Legth:Not by size or on demand

application: mainly used in automobile industry, machinery industry, oil cylinder, automobile shock absorber.

Description Specification

1: Precision seamless steel pipe is a high-precision steel pipe through a cold drawn or hot rolling process,due to this tube

inside and outside wall without oxide layer, withstand high pressure and without leakage, high-precision, high-quality finish,

cold-formed without deformation,bellig, flattening cracks etc. Therefore, the products are mainly used in the production of

pneumatic or hydraulic components such as the cylinder or cylinder.

Product Feature

1: Small outer diameter

2:Due to the high precision so it can be short run production

3:The cold drawn products with high precision and surface is better

4: Steel pipe cross area more complex

5: Superior performance of steel pipe, the metal is more dense

Specification

Φ4×0.5

Φ16×0.5

Φ26×1.8

Φ35×9.0

Φ4×0.8

Φ16×0.8

Φ26×2.0

Φ35×10

Φ4×1.0

Φ16×1.0

Φ26×2.2

Φ38×0.5

Φ4×1.2

Φ16×1.2

Φ26×2.5

Φ38×0.8

Φ5×0.5

Φ16×1.5

Φ26×2.8

Φ38×1.0

Φ5×0.8

Φ16×1.8

Φ26×3.0

Φ38×1.2

Φ48×5.0

Φ70×2.8

Φ90×10

Φ130×14

Φ48×5.5

Φ70×3.0

Φ90×12

Φ130×16

Φ48×6.0

Φ70×3.5

Φ90×14

Φ130×18

Φ48×7.0

Φ70×4.0

Φ90×16

Φ140×2.5

Φ48×8.0

Φ70×4.5

Φ95×2.0

Φ140×2.8

Φ48×9.0

Φ70×5.0

Φ95×2.2

Φ140×3.0

Precision steel tube size tolerance

Dimensional tolerances (wall thickness deviation ± 5%)

The size of the diameter

H8

H9

H10

30

+0.0330

+0.0520

+0.0840

30-50

+0.0390

+0.0620

+0.1000

50-80

+0.0460

+0.0740

+0.1200

80-120

+0.0540

+0.0870

+0.1400

120-180

+0.0630

+0.1000

+0.1600

180-250

+0.0720

+0.1150

+0.1850

250-315

+0.0810

+0.1300

+0.2100

315-400

+0.0890

+0.1400

+0.2300
