316l 310 310s 321 304 Seamless Stainless Steel Pipes / Tube Thickness 0.1 - 40mm
316l 310 310s 321 304 Seamless Stainless Steel Pipes / Tube Thickness 0.1 - 40mm
316l 310 310s 321 304 Seamless Stainless Steel Pipes / Tube Thickness 0.1 - 40mm
316l 310 310s 321 304 Seamless Stainless Steel Pipes / Tube Thickness 0.1 - 40mm
316l 310 310s 321 304 Seamless Stainless Steel Pipes / Tube Thickness 0.1 - 40mm
316l 310 310s 321 304 Seamless Stainless Steel Pipes / Tube Thickness 0.1 - 40mm
Specifications
Brand Name :
TISCO
Model Number :
ASTM A213,A312,ASTM A269,ASTM A778,ASTM A789,DIN 17456, DIN17457,DIN 17459,JIS G3459,JIS G3463,GOST9941,EN10216, BS3605, GB13296
Certification :
AISI,ASTM,DIN,JIS,BS,NB
Place of Origin :
China
MOQ :
1MT
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
2000MT Per Month
Delivery Time :
7-15 days
Packaging Details :
Waterproof paper and wooden pallet or according to customer's request
Technique :
hot rolled and cold rolled
Thickness :
2 - 200 mm
Length :
12M, 6m, 3-12m
Grade :
300 Series, 310S, 316Ti, 316L, 316, 304, 304L
Application :
Industry
Standard :
AISI,ASTM,DIN,JIS,BS,NB
Description

— 304,304L Stainless Steel Pipe —

Description

Stainless steel pipe are light weight and are widely used in the manufacture of mechanical parts and engineering structures. Mainly used in petroleum, chemical, medical, food, light industry, mechanical instrumentation and other industrial pipelines and mechanical structural components

· Material: 201,302,303,304,304l,316,316l,321,309s,310s,904l etc

· Size(round pipe): 9.5-219 mm or customized

· Size (square pipe): 10×10-150×100 mm or customized

· Size (oval pipe): 30×15,80×40 mm or customized

· Thickness: 0.24-3 mm

· Length: 6m or according to customer’s request

· Outer diameter: 8-219mm

· Tolerance: Outer diameter :±0.2mm Thickness :±0.02mm Length :±0.5mm

· Process method: Code drawn, annealed with nitrogen protection, ultrasonic,automatic shape, polished

· Finishing: A: sanded B: 400#-600# mirror C: hairline brushed D: TIN titanlum

· E : HL brushed & mirror (two kinds of finishing for one pipe)

Standard: ASTM EN DIN GB ISO JIS Certification: SGS,ISO,ROHS
Length: 6000-25000mm,etc Surface:

2B,2D,BA,NO.1,NO.4,NO.8,8K,Pickling,Bright;

mirror,

checkered,embossed,hair line, sand blast, Brush, etching, etc
Diameter: 3mm--1000mm, etc Production Process: Cold Drawn,Cold Rolled,Bright Anneal etc
Thickness: 0.5-40mm Surface Treatment: Standard export package, suit for all kinds of transport, as required.
Export Packing: Waterproof Paper, Steel Strip Packed and other Standard Export Seaworthy Package, or customized package Loading Port: Pickled,Passivation,Inside & Outside Mechanical Polishing, BA, Electropolishing (EP)
Heat Treatment Condition: Solution Annealing and water rapid quenched, Bright Annealing,Stess Relieving Heat Treatment for U tubes Trade Terms: FOB, CNF,CIF
Grade: 201,202,304,304L,309,309S,310S,316,316L,316Ti,317L,321,347H,409,409L,410,410S,420(420J1,420J2),430,436,439,441,444,446 etc1.4301, 1.4307, 1.4541, 1.4401, 1.4404 ,1.4571, 1.4438, 1.4539, 1.4547, 1.4529, 1.4562, 1.4410, 1.4878, 1.4845, 1.4828, 1.4876, 2.4858, 2.4819
Advantage: 1. high quality surface, clean finished2. corrosion & oxidation resistance, more durable3. high ductility and good toughness4. high strength and to deform5. the use to diversity
Container Size: 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High)

Grade

C

(Max)

Mn

(Max)

P

(Max)

S

(Max)

Si

(Max)

 Cr Ni Mo Nitrgeo(Max) Cu/Other
201 0.15 5.5-7.5 0.06 0.03 1.0 16.0-18.0 0.5-1.0 -- 0.25 --
202 0.15 7.5-10.0 0.06 0.03 1.0 17.0-19.0 1.5-2.5 -- 0.25 --
304 0.08 2.0 0.045 0.03 1.0 18.0-20.0 8.0-10.0 -- 1.0
304L 0.03 2.0 0.045 0.03 1.0 18.0-20.0 8.01-10.5 -- 0.1 --
309S 0.08 2.0 0.045 0.03 1.0 22.0-24.0 12.0-15.0 -- -- --
310S 0.08 2.0 0.045 0.03 1.5 24.0-26.0 19.0-22.0 -- -- --
316L 0.03 2.0 0.045 0.03 1.0 16.0-18.0 10.0-14.0 2.0-3.0 0.1
321 0.08 2.0 0.045 0.03 0.75 17.0-19.0 9.0-12.0 -- 0.1 --
2205 0.025 1.27 0.026 0.0015 0.58 ≤22.50 ≤5.20 ≤3.10 -- --
904L 0.02 2.0 0.045 0.035 1.0 19.0-23.0 23.0-28.0 4.0-5.0 -- --

Grade TS(Mpa) YS(Mpa) EL(%) RRA(%) Density
201 ≥520 ≥275 55-60 - 7.93
202 ≥590 ≥245 - - 7.93
304 ≥520 ≥205 ≥40 ≥60 7.93
304L ≥520 ≥205 ≥40 ≥60 7.93
309S ≥515 ≥205 ≥40 ≥50 7.98
310S ≥520 ≥205 ≥40 ≥50 7.98
321 ≥520 ≥205 ≥40 ≥50 7.98
316L ≥485 ≥170 ≥30 ≥40 7.98
