Prepainted Galvanized Steel Sheets Coil 1000MM Color Coated DX52D

Specifications

Brand Name :

TISCO

Model Number :

SGCC SECC SGCD PPGI DX51D DX54D S250GD S550GD

Certification :

ce, ISO9001,RoHS, IBR

Place of Origin :

Jiangsu，China

MOQ :

1ton

Price :

Negotiable

Payment Terms :

L/C, T/T, Western Union

Supply Ability :

20000 Ton/Tons per Month

Delivery Time :

3-15 days

Packaging Details :

Covered with a layer of plastic film and cardboard, packed on the wooden pallets, bound with iron belt, loaded in the containers

Standard :

AiSi, ASTM, bs, DIN, GB, JIS

Processing Service :

Cutting

Application :

ROOF

Technique :

Cold Rolled

Surface Treatment :

galvanized

Width :

762MM/914MM/1000MM

Type :

Galvanized Steel coil

Description

— Galvanized Steel Coil —

Description

The iron elements in steel are incredibly prone to rusting, but the addition of zinc acts as a protective buffer between the steel and any moisture or oxygen. Galvanized steel is very protective, including sharp corners and recesses that couldn't be protected with other coatings, making it resistant to damage.

The zinc coating of hot-dipped galvanized steel will last in the harshest soil is 35 to 50 years and in less corrosive soil 75 years or more. Although humidity affects corrosion, temperature itself has less of an impact.

Product Name	Galvanized coil
Thickness	0.13-3.0mm
Width	500mm-1500mm
Length	As customer's request
Zn coating	0.13-0.8 mm is 30-150 g/m2; 0.8-1.5 mm is 30-180 g/m2;1.5-6.0 mm is 30-275 g/m2
Coil ID	600-1500 mm,Normal width is 91 4/1000/1219/1250/1500 mm
Steel grade	DX51D,DX52D,DC01,DC02,SGHC
Surface	regular/mini/big/zero spangle,skin pass, chromated, unoiled, dry
Packaging	seaworthy export standard package, or according to the customers’requirement
Delivery time	With 15 –25 days after receipt of deposit or L/C
Market	North/South America, Europe, Asia,Africa,Mid East
Productivity	2000 ton /month
Warehose Stcok	Normal Grade 10000 tons per month

STEEL GRADE	CHEMICAL COMPOSITION %					MECHANIC PROPERTY			C.B OF	COATING
	C	Si	Mn	S	P	T.S	Y.S	E.L	COATING	COATING
	x103	x103	x102	x103	x103	Mpa	Mpa	%	d=0 180°	G/M²
JIS G3302 SGCC	12	30	41	31	21	480	300	13	OK	Z60-150
JIS G3302 SGCH	12	10	21	18	8	680	650	20	OK	Z60-150
ASTM A653 CS.B	29	30	60	35	30	386	250-380	20	OK	Z60-275
DX51D+Z	20	21	18	1.8	11	355	245	38	OK	Z60-275
G550	12	6	73	5	17	715	654	8	OK	Z60-275
