Single Decapping Head Auto Loading PLC Barrel Filling Machine
Single Decapping Head Auto Loading PLC Barrel Filling Machine
Single Decapping Head Auto Loading PLC Barrel Filling Machine
Single Decapping Head Auto Loading PLC Barrel Filling Machine
Single Decapping Head Auto Loading PLC Barrel Filling Machine
Single Decapping Head Auto Loading PLC Barrel Filling Machine
Single Decapping Head Auto Loading PLC Barrel Filling Machine
Single Decapping Head Auto Loading PLC Barrel Filling Machine
Specifications
Brand Name :
FILLPACK
Model Number :
QGF-120
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 SET
Price :
2700 USD
Payment Terms :
L/C,D/A,D/P,D/P,Western Union,MoneyGram
Supply Ability :
1 SET PER WEEK
Delivery Time :
20 DAYS
Packaging Details :
WOODEN CASE PACKING
Control: :
PLC
Gas pressure: :
0.4-0.6Mpa
Function: :
Barrel filling
Gas Consumption: :
0.37 m3/min
Barrel size: :
270*490mm
Certification: :
CE ISO
Weight: :
680kg
After-sales Service Provided: :
Online support,
Dimension(L*W*H): :
4500*1600*2400mm
Description

single decapping head gallon bottle water filling line / plant / device auto loading

1. All PLC control, full-automatic working, touch-screen control panel, easy to operate
2. Rotary filling style, fast, smoothly & steadily, ensure the high output capacity
3. No bottle no filling, no bottle no capping & high filling precision,
4. High precision filling nozzle, ensure no water drip during filling & same water level in the bottles
5. All 304 or 316L stainless steel contact parts, fine polish, ensure meet the Food Grade standards
6. Available Capacity of these series 5 gallon filling machinery: ( based on 5 gallon bottle)from 100BPh to 1200BPH

Characters

1, The whole 3 gallon bottle water filling machine is controlled by PLC system, all cylinder travel is calculated in advance for driven distance;


2, The 3 gallon bottle water filling machine can work under automatic model, manual model is for machine checking;

Parameters
Rinsing pump 1
0.37KW
Rinsing pump 2
0.37KW
Filling pump
0.55KW
Cap sorting motor
0.09KW
Dimension
3100*570*1450mm (cap loader at side)/2700*570*1720mm (cap loader at top)
+ 2000mm conveyor
Weight
400kg
