Wire Gauge 2.0-4.0mm Color Silver Packing Pallet Galvanized Gabion Box
Wire Gauge 2.0-4.0mm Color Silver Packing Pallet Galvanized Gabion Box
Wire Gauge 2.0-4.0mm Color Silver Packing Pallet Galvanized Gabion Box
Wire Gauge 2.0-4.0mm Color Silver Packing Pallet Galvanized Gabion Box
Wire Gauge 2.0-4.0mm Color Silver Packing Pallet Galvanized Gabion Box
Wire Gauge 2.0-4.0mm Color Silver Packing Pallet Galvanized Gabion Box
Wire Gauge 2.0-4.0mm Color Silver Packing Pallet Galvanized Gabion Box
Wire Gauge 2.0-4.0mm Color Silver Packing Pallet Galvanized Gabion Box
Specifications
Brand Name :
Zhuoda
Model Number :
ZD-04
Certification :
ISO9001
Place of Origin :
Anping China
MOQ :
100 Sets
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
10000 Sets
Delivery Time :
5-7days
Packaging Details :
BY Pallets
Model number :
Galvanized Gabion Box
Material :
Galvanized Wire, PVC Coated Wire
Type :
Weave Mesh
Application: :
Water And Soil Protection
Hole Shape :
Hexagonal Mesh
Wire Gauge :
2.0mm, 2.7mm, 3mm 3.5mm 4mm
Surface Treatment :
Hot Dipped Galvanized
Feature :
Corrosion resistance
Gabion Size :
2x1x1,3x1x1,4x1x1,6x2x0.3
Mesh Size :
60x80 80x100 80x120 100x120
Description

Wire Gauge 2.0-4.0mm Color Silver Packing Pallet Galvanized Gabion Box

Galvanized Gabion Box Information:

Welded gabion fence is high quality steel mesh.They can be filled on site with hard durable stone materials to form mass gravity retaining structures.Owing to their inflexibility.welded gabions can not adapt to differential settlement or be used in water course. In comparison with woven wire gabion, welded gabion offer a higher strength.In order to meet different project requirements,various wire diameters and unit sizes are available for welded gabion boxes.

1. Materials:

Hot dipped galvanized wire

Hot dipped galvanized wire+pvc

2. Application:

1.gabions for soil & river bank retaining walls

2.gabions for coastal & beach protection

3.slope protection net

4.mechanically stablized earth walls

5.mass-gravity retaining walls

6.rivei canal lining

7gabion weirs

8.achitectural applications

9.sound barriers

4.Features:

1)Flexible structure to adapt to changes in the slope without being destroyed, better than the rigid structure with the security and stability; 2).Anti-erosion ability, able to withstand the maximum flow rate of up to 6m / s .

Galvanized Gabion Box specificaiton:

Length Width Height Diaphragm CUM The tolerance
M M M Unit M3
2 1 0.3 1 0.6
3 1 0.3 2 0.9
4 1 0.3 3 1.2 length+-3%
2 1 0.5 1 1 width+-5%
3 1 0.5 2 1.5 height+-5%
4 1 0.5 3 2
1 1 0.5 0 1 Hole size
1.5 1 1 0 1.5 60x80mm
2 1 1 1 2 80x100mm
3 1 1 2 3 100x120mm
4 1 1 3 4

Galvanized Gabion Box Package:

1.With plastic weaving bags outside

2.With wooden pallet cloth

3.Less transport freight. It can be folded together for transport and further installation.

Wire Gauge 2.0-4.0mm Color Silver Packing Pallet Galvanized Gabion BoxWire Gauge 2.0-4.0mm Color Silver Packing Pallet Galvanized Gabion BoxWire Gauge 2.0-4.0mm Color Silver Packing Pallet Galvanized Gabion Box
