OEM 2x1x1m Gabion Retaining Wall Rockfall Barrier Heavy Duty Rustproof
OEM 2x1x1m Gabion Retaining Wall Rockfall Barrier Heavy Duty Rustproof
Specifications
Brand Name :
KN
Model Number :
gabion retaining wall
Certification :
CE ISO SGS COC PVOC
Place of Origin :
CN
MOQ :
100 pc
Price :
USD 12-17
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
1000 pc per day
Delivery Time :
15 work days
Packaging Details :
pallet
Application :
erosion control, retaining walls, river bank protection, landscaping
Surface Treatment :
hot-dipped galvanized, PVC coated
Mesh Size :
60x80mm, 80x100mm, 100x120mm
Size :
1x1x1m, 2x1x1m, 3x1x1m, 4x1x1m
Wire Diameter :
2.0-4.0mm
Material :
galvanized steel wire
Features :
durable, flexible, easy to install
Edge Wire :
3.4mm
Product Name :
Woven Gabion Cage 2x1x1m Hydraulic Engineering Rockfall Barrier Heavy Duty Rustproof
Key Words :
gabion retaining wall
Description

Gabion Retaining Wall 2x1x1m Hydraulic Engineering Rockfall Barrier Heavy Duty Rustproof

Available in a range of sizes, including 2x1x1m, this gabion box can be tailored to fit specific project requirements, making it suitable for various construction applications.

Key Features

  • Material: Hot-dip galvanized steel (Zn ≥ 250g/m²), PVC-coated options (0.5mm thickness)
  • Design: Hexagonal double-twist mesh, 90x110mm standard apertures (customizable)
  • Coatings: Epoxy/Zinc-Aluminum alloy for marine/coastal applications
  • Fillers: Crushed rock, recycled concrete, or vegetated soil (client-specified)

Technical Advantages
✓ 3x Lifespan: 50-100 years corrosion resistance
✓ Load Capacity: Up to 50kN/m² vertical pressure
✓ Eco-Friendly: 100% recyclable materials with zero chemical runoff
✓ Modular Assembly: Interlocking panels for 70% faster installation

Applications

  • Civil Engineering: Riverbank stabilization, highway embankments
  • Architecture: Retaining walls, sound barriers, decorative façades
  • Disaster Prevention: Flood control barriers, landslide mitigation systems
  • Mining: Tailings dam reinforcement, slope retention
    Packaging Details
    Gabion baskets Packing: 40-100set/ bundle, binding with steel strape or strands; 40-100set/bundle; Then use wooden tray; Some sizes in rolls; As customer's requirement

    1.bnudle package
    2.Several pieces of gabions to a pallet,pallets put into containers.
    3.70pieces to a bundle, 24-26Tons to a 40HQ

Customization Services

  • Sizes: 2x1x1m (standard) up to 6x2x1m (heavy-duty)
  • Wire Diameters: 2.2mm – 4.0mm (3.0mm recommended for high-load zones)
  • Colors: Metallic Silver (standard), Green/Black PVC coating (urban projects)
gabion specifications Mesh hole modle
8x10cm 6x8cm
Length(m) Width(m) Height(m) Galvanized or PVC coated Galvanized or PVC coated
Mesh diameter Zinc Mesh diameter Zinc
2 1 1 2.7mm >245g/m² 2.0mm >215g/m²
3 1 1 Side wire diameter Zinc Side wire diameter Zinc
4 1 1 3.4mm >265g/² 2.7mm >245g/m²
6 1 1 Binding wire diameter of 2.7m Binding wire diameter of 2.0m
