Specifications
Model Number :
FT-49OGM500
Brand Name :
FUTENG
Place of Origin :
China
MOQ :
1000 Pieces
Price :
Negotiable
Certification :
CE/ROHS/FCC/REACH/ISO14001/ ISO9001/ISO45001/IATF16949
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
8000 0000
Delivery Time :
15-30 days/Negotiable
Packaging Details :
Standard Export Carton & Customzied
Name :
DC Spur Gear Motor
Continuous Current(A) :
about 430mA-2500mA
Efficiency :
65%-90%
Torque :
1-55kgf.cm, 11.6/12.6/12/13.5(g.cm)
Type :
Gear Motor
Usage :
Boat, Car, Electric Bicycle, Fan, Home Appliance, Cosmetic Instrument, Smart Home
Warranty :
3 months ~ 1 year
Geared motor model :
FT-49OGM500
Gear box size :
49mm
Voltage :
1-24V
Speed :
2rpm-500rpm
Rotating speed :
2700/3100/2700/4000(rpm)
Rated voltage :
3v/5v/6v/12v
Current :
20/26/30/22(mA)
Output :
0.26/0.27/0.27/0.29(w)
Description

Wholesale 12v 24v Dc Spur Gear Motor For Shared Automatic Tissue Machine



VR
12V 24V DC Spur Gear Motor Explosion Proof For Shared Automatic Tissue Machine

FT MOTOR

FT MOTOR Geared motor model: FT-49OGM500 Gearbox Diameter: Ø49mm Voltage: 1-24V Speed: 1rpm-2000rpm DC gear motors are widely used: Robots, electronic locks, public bicycle locks, ATM machines, electric glue guns, household appliances, 3D printing pens, electric toothbrushes, office equipment, massage health care, beauty and fitness equipment, medical equipment, toys, electric daily necessities, automotive automatic facilities, etc.
Gearbox Data:


Gear stage
4
5
Reduction ratio (K)
45,60,80,100
150,201,309,426,530
Gear box length L(mm)
10.5
10.5
Rated torque (kg·cm)
2
4
Instant torque (kg·cm)
5
7
Gearbox efficiency (%)
65%
59%
Motor Data









Motor Model

No Load

Load



Stall

Motor Model
Rated Voltage
Speed
Current
Speed
Current
Output
Torque
Current
Torque

V
(rpm)
(mA)
(rpm)
(mA)
(w)
(g·cm)
(mA)
(g·cm)
FT-500
6
2700
20
2180
84
0.26
11.6
350
60
FT-500
5
3100
26
2540
120
0.27
12.6
540
70
FT-500
3
2700
30
2230
160
0.27
12
680
60
FT-500
12
4000
22
3200
125
0.29
13.5
460
75
