High Torque 19460 Motors Brushless DC For Multirotor Drone With 54'' Propeller 100V 300A Controller
High Torque 19460 Motors Brushless DC For Multirotor Drone With 54'' Propeller 100V 300A Controller
High Torque 19460 Motors Brushless DC For Multirotor Drone With 54'' Propeller 100V 300A Controller
High Torque 19460 Motors Brushless DC For Multirotor Drone With 54'' Propeller 100V 300A Controller
High Torque 19460 Motors Brushless DC For Multirotor Drone With 54'' Propeller 100V 300A Controller
High Torque 19460 Motors Brushless DC For Multirotor Drone With 54'' Propeller 100V 300A Controller
High Torque 19460 Motors Brushless DC For Multirotor Drone With 54'' Propeller 100V 300A Controller
High Torque 19460 Motors Brushless DC For Multirotor Drone With 54'' Propeller 100V 300A Controller
Specifications
Brand Name :
Furious Motor
Model Number :
19460
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
$2268
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
3000 pcs per month
Delivery Time :
5-8 working days
Packaging Details :
Carton witn protection (EPE)
Model :
19460
Dimension :
194mm * 60mm
KV :
35
Max. Thrust :
95KG
Max. Torque :
61N.m
Max. RPM :
3009
Suggested ESC :
24S 200A
Suggested Prop :
54 inch propeller
Max. Current :
265A
Max. Voltage :
92V
Max. Power :
23KW
Li - Po :
14S - 24S
Hall Sensor :
Optional
Weight :
6.16KG
Application :
Paramotor, paraglider
Description

Intoroduction

The 19460 brushless motor is engineered specifically for paramotors and paragliders, delivering remarkable power and efficiency for aerial adventures. Crafted for top-tier performance, it integrates effortlessly with a 54-inch propeller and a 24S 300A motor controller, generating a robust thrust of 95kg.
A key highlight is its adaptability, enabling pilots to customize setups to achieve peak performance tailored to their needs. Whether you're gliding effortlessly or tackling demanding lift tasks, the 19460 ensures dependable power and a superior flight experience.

Tech Specs

System

Max. Thrsut 95 kg / rotor
Takeoff Weight 25 kg - 45 kg / rotor
Suggested ESC 24 S 300 A
Suggested Propeller 54 inch 2-blade propeller
Suggested Battery 12 S - 24 S
Working Temperature -20 °C ~ 50 °C
Total Weight 6.16 kg
Application Paramotor, paraglider

Motor

Model 194-60
KV 35
Max. Thrsut 95 kg
Max. Torque 61 N·m
Max. Voltage 92 V
Max. Current 165 A
Max. Power 23 KW
Max. RPM 3009
Dimension 194 mm * 60 mm
Weight 4.75 kg

ESC

Model 24 S 300 A
Suggested Battery 12 S ~ 24 S (Li-Po)
PMW Signal 3.3 V / 5 V
Pulse Width 900 us ~ 2000 us
Signal Frequency 50 Hz ~ 400 Hz
Max. Input Voltage DC 50 V ~ 100 V
Max. Input Current 300 A
Weight 812 g
Dimension 140.5 mm * 66.6 mm * 47.1 mm

Propeller

Model 54 inch 2-blade
Diameter 54 inch
Material Carbon fiber
Weight 600 g

Details

High Torque 19460 Motors Brushless DC For Multirotor Drone With 54'' Propeller 100V 300A ControllerHigh Torque 19460 Motors Brushless DC For Multirotor Drone With 54'' Propeller 100V 300A ControllerHigh Torque 19460 Motors Brushless DC For Multirotor Drone With 54'' Propeller 100V 300A ControllerHigh Torque 19460 Motors Brushless DC For Multirotor Drone With 54'' Propeller 100V 300A ControllerHigh Torque 19460 Motors Brushless DC For Multirotor Drone With 54'' Propeller 100V 300A ControllerHigh Torque 19460 Motors Brushless DC For Multirotor Drone With 54'' Propeller 100V 300A ControllerHigh Torque 19460 Motors Brushless DC For Multirotor Drone With 54'' Propeller 100V 300A Controller​

High-Torque 19460 Brushless DC Motor For Multirotor Drone With 54-Inch Propeller And 100V 300A Controller
