Heavy Duty DC Brushless Motors 120100 61kg Thrust For VTOL Drone
Heavy Duty DC Brushless Motors 120100 61kg Thrust For VTOL Drone
Heavy Duty DC Brushless Motors 120100 61kg Thrust For VTOL Drone
Heavy Duty DC Brushless Motors 120100 61kg Thrust For VTOL Drone
Heavy Duty DC Brushless Motors 120100 61kg Thrust For VTOL Drone
Heavy Duty DC Brushless Motors 120100 61kg Thrust For VTOL Drone
Heavy Duty DC Brushless Motors 120100 61kg Thrust For VTOL Drone
Heavy Duty DC Brushless Motors 120100 61kg Thrust For VTOL Drone
Specifications
Brand Name :
Furious Motor
Model Number :
120100
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
$428
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
3000 pcs per month
Delivery Time :
5-8 working days
Packaging Details :
Carton witn protection (EPE)
Model :
120100
Dimension :
120mm * 100mm
KV :
50
Max. Thrust :
61KG
Max. Torque :
33N.m
Max. RPM :
3468
Suggested ESC :
24S 200A
Suggested Prop :
45 inch propeller
Max. Current :
165A
Max. Voltage :
94V
Max. Power :
12.3KW
Li - Po :
14S - 24S
Hall Sensor :
Optional
Weight :
3.9KG
Application :
Drone, paramotor
Description

Intoroduction

The 120100 brushless motor is meticulously engineered to power a wide array of aerial platforms, such as large drones, UAVs, paramotors, paragliders, multirotor systems, and unmanned aircraft. Precision-tuned for exceptional performance, this motor integrates seamlessly with a 45-inch propeller and a 24S 200A motor controller, ensuring accurate control and optimized power distribution.
Boasting a remarkable maximum thrust of 61kg, it has become a top pick for demanding drone applications. Elevate your aerial missions with enhanced stability, as the 120100 Brushless Motor redefines standards for reliability and precision in propulsion systems.

Tech Specs

Model 120100
Type Brushless DC motor
KV 50
Suggested ESC 24 S 200 A
Suggested Propeller 45 inch
Max. Thrust 61 kg
Max. Torque 33 N·m
Max. RPM 3468
Li-Po 14 S ~ 24 S
Max. Voltage 94 V
Max. Current 165 A
Max. Power 12.3 kW
Motor Dimension 120 mm * 100 mm
Weight 3.9 kg
Application Multi rotor drone, heavy lift drone, paramotor

Details

Heavy Duty DC Brushless Motors 120100 61kg Thrust For VTOL DroneHeavy Duty DC Brushless Motors 120100 61kg Thrust For VTOL DroneHeavy Duty DC Brushless Motors 120100 61kg Thrust For VTOL DroneHeavy Duty DC Brushless Motors 120100 61kg Thrust For VTOL DroneHeavy Duty DC Brushless Motors 120100 61kg Thrust For VTOL DroneHeavy Duty DC Brushless Motors 120100 61kg Thrust For VTOL Drone

Heavy-Duty Brushless DC Motor 120100 61kg Thrust For VTOL Drone With Durable Performance
