Energy Saving DIP346 P10 LED Stage Screen Rental Waterproof LED Module 10000dots / m2
Energy Saving DIP346 P10 LED Stage Screen Rental Waterproof LED Module 10000dots / m2
Energy Saving DIP346 P10 LED Stage Screen Rental Waterproof LED Module 10000dots / m2
Energy Saving DIP346 P10 LED Stage Screen Rental Waterproof LED Module 10000dots / m2
Specifications
Brand Name :
Viso
Model Number :
PH10
Certification :
UL CE ROHS ISO ETL SGS SAA Fcc EMC
Place of Origin :
China
MOQ :
1 Square Meter
Price :
Negotiation
Payment Terms :
L/C T/T Western Union Paypal Credit Card, MoneyGram, VISA
Supply Ability :
5,000 square meters per month
Delivery Time :
4-6 work days
Packaging Details :
Wooden box or Flight case
Pixel Pitch :
10mm
Density :
10000dots / m2
Screen Resolution :
64 x32 pixels
Display Area :
0.72meter(w) * 0.4meter(h)= 0.288 sq.m
Show word Number :
2 pcs (W)*2pcs(h)=4 pcs
Show Content :
Single color Words and Pictures
Thickness :
≤9cm
Frame structure :
Aluminum Frame (Silver White,black)
Screen Weight :
30kg / m2
Description


Energy Saving DIP346 P10 Led Stage Screen Rental Waterproof Led Module 10000dots / m2

Technical features :

1. Preeminent effects : Clear and stable pictures without distortion and disturbance .

2. High quality : adopting first-class chips and wafers imported from abroad .

3. Flexible form : continuity, overlying, combination of dynamic and static playing, various effects include rolling moving, typewriting, gradual changing and so on .

4. off-line running function : adopting the monolithic design technology and computer string communication way , which can operate in off-line state setting the dates and revising a data via the telephone line.

Information :

1. Applications : The applications for Multi Line Displays are endless.

2. Up-dated Multi Line LED Electronic Displays are easy to use and can be up-dated quickly and with no technical expertise

3. Character heights : Available in a variety of character heights : although if you have a multi line display made up from a number of Bi-Line displays, you can show a single line of text in double height format which will usually double these heights. Larger height signs are also available.

4. Color : LED Colour Options are : RED , GREEN , YELLOW , or TRI-COLOUR , blue and white are also available

5. Various speed and Characters : The signs can display most different Characters and Graphic Symbols.

The signs can run at variable Speeds , and have various display features including Bold , Run Left/Right etc.

6. Can be controlled remotely , like WIFI , GSM , GPRS , 3G , 4G ,5G .

LED parameter :
Pixel Name P10
Pixel Diameter 10mm
Pixel Pitch 10mm
Density 10000dots / m2

Screen

Body

 Screen Resolution 64 x32 pixels
Display Area 0.72meter(w) * 0.4meter(h)= 0.288 sq.m
Show word Number 2 pcs (W)*2pcs(h)=4 pcs
Show Content Single color Words and Pictures
Thickness ≤9cm
Frame structure Aluminum Frame (Silver White,black)
Screen Weight 30kg / m2

Power

Supply

 Working Voltage 220V

Max. power

consumption

 ≤ 450W / m2
Average Consumption 100 ~ 150W / m2

Control

System

 Control Method Asynchronous / Synchronous
OS Above WINDOWS 98 xp

Main

Technical

Parameter

 Driving IC HC595
LED driving Method 1 / 4 scan driving
Refresh frequency ≥ 180HZ
Frame frequency ≥ 75 frame / s
Gray scale / color 256 / 256 grade
IV ≥ 2000cd / m2
Best viewing Angle ± 60º

Optimum Viewing

Distance

 10 ~ 60m
Effort communicate distance Within 120m
Working temperature -20°C~ +60°C
RH 15 % - 85 %
Software LED Universal player (MDK)
