HD Full Color Transparent LED Display RGB with 1 / 4 Scan Constant Current Driving Mode
HD Full Color Transparent LED Display RGB with 1 / 4 Scan Constant Current Driving Mode
HD Full Color Transparent LED Display RGB with 1 / 4 Scan Constant Current Driving Mode
HD Full Color Transparent LED Display RGB with 1 / 4 Scan Constant Current Driving Mode
Specifications
Brand Name :
Vios
Model Number :
PH6
Certification :
UL CE ROHS ISO ETL SGS SAA Fcc EMC
Place of Origin :
China
MOQ :
1 Square Meter
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union, Paypal, Credit Card, MoneyGram, VISA
Supply Ability :
5,000 square meters per month
Delivery Time :
3-5 work days
Packaging Details :
Wooden box or Flight case
Led Chip :
Epistar/Cree/Nichia
LED :
DIP346
Power Supply :
Meanwell/G-enery/YHY
Driving Mode :
1/4 Scan Constant Current
8-100 Meters :
Viewing Distance
Working Temperature :
-20°C-50°C
Screen Dimension :
4m X3m, 6mx4m,10x3m, 12x3m
Life Span :
>100,000hours
Best Viewing Angle :
110°/65°
Display Function :
Video
Description


HD Full Color Transparent LED Display RGB with 1 / 4 Scan Constant Current Driving Mode

Product Description:

1. Weather resistance:

IP65 rating delivers best waterproof effect that ensures our product's stable broadcasting in harshest weather condition.

2. World-class image quality

Strict system control and pixel to pixel correction make the image smooth and uniformity.

3. System flexibility:

Able to show a variety of content of video, animation, graphic and so on.

4. Service facility:

Modular design makes module individual and can fix easily without affecting others.

Technical Specification:

Model PH16 outdoor full color LED display
Pixel pitch 16 mm
Pixel density 3906 dots/m2
Pixel configuration 2R1G1B / RGB
LED specification DIP546
Module matrix (pixel dots) 16*8
Module size 256*128 mm
Module power consumption 35 W
Cabinet matrix (pixel dots) 64*48
Cabinet size 1024*768*120 mm
Cabinet pixel density 3072 dots
Protection level IP65
Cabinet weight 60 kg
Best viewing distance 14 m
Best viewing angle 110° (horizontal)
Max power consumption 1000 W/m2
Control mode Synchronization
Graphics card DVI Graphics card
Drive mode statci constant current drive
Exchange frame rate ≥60 HZ
Refresh rate ≥400 HZ
Grey grade 4096 grade
White balance brightness ≥6500 cd/m2
Working environment temperature -20°C - +50°C
Working voltage AC 100-240 V, 50-60 Hz
Brightness adjusted way Manual, 256 level; Auto, 8 level.
MTBF ≥10,000 h
Screen lifetime 100 000 h
Blind dot rate 0.0003
Computer operating system WIN98, WINXP, WIN2000, etc.
Video signal RF, S-Video, RGB, RGBHV, YUV, YC, etc.
Control system DVI Graphics card + sending card + receiving card
PC display mode 1024*768
Software LED studio 5. with CE, ROHS, FCC Certification, ISO 9002


P8 outdoor full color led module/display
P10 outdoor full color led module/display
P12 outdoor full color led module/display
P16 outdoor full color led module/display
P20 outdoor full color led module/display
P25 outdoor full color led module/display

indoor series:

P3,P4,P5,P6,P7.62,P6,P10 SMD indoor full color led module/display.
