Home / Hotal / Office Full HD LED TV SMD RGB 2121 LED Backdrop Curtain 400 * 300mm
Home / Hotal / Office Full HD LED TV SMD RGB 2121 LED Backdrop Curtain 400 * 300mm
Home / Hotal / Office Full HD LED TV SMD RGB 2121 LED Backdrop Curtain 400 * 300mm
Home / Hotal / Office Full HD LED TV SMD RGB 2121 LED Backdrop Curtain 400 * 300mm
Specifications
Brand Name :
Vios
Model Number :
PH1.66/PH2.5/PH3/P3.91/P4.81/P4/P5
Certification :
UL CE ROHS ISO ETL SGS SAA Fcc EMC
Place of Origin :
China
MOQ :
1 Square Meter
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union, Paypal, Credit Card, MoneyGram, VISA
Supply Ability :
5,000 square meters per month
Delivery Time :
4-6work day
Packaging Details :
Wooden box or Flight case
LED Chip :
Epistar, Silan, Opto, Cree, Nicha
Screen Dimension :
400*300mm
Power Supply :
Meanwell
LED Type :
SMD 1010 Black
Life-span :
100,000Hours
Control System :
Ledstudio Or NovaStudio
Cabinet Materials :
Die-casting Aluminum
Macroblock :
Macroblock
Description


Product Characteristics:

1: Light Cabinet size 512mm×512mm, just 12.5kg in weight comparing to 8 KGs of conventional same size cabinet. Available to lift the cabinet by One-handed, saving much assembling time.
2: Thin Adopted Die-casting aluminum cabinet with features of high strength, toughness, Precision and hard deformation. Just 89mm in thickness as a whole comparing to 160mm of conventional cabinet.
3: Fast Use the facile connection lock in the cabinet, Assembling: Push the lock and then turn the revolving handle; Dismantling: Turn the handle and pull the lock. 10s/pcs.
4: Easy Used modular design, any cabinet of the screen is free of assembling and dismantling.
Compatible New structure design satisfy the hoisting assembling and stacking assembling, Cabinet standardization, compatible Outdoor & Indoor variety pixel pitches.
5: Low Excellent heat dissipation design, no fans and air conditioning are required. Prime structure design, no tools are required.


Technology Parameter & Specifications:

itemsepcification
LED shapeSMD 1010 Black
Pixel pitch1.667mm
Cabinet resolution240(W)*180(H)
Module resolution120(W)*60(H)
module Configuration2×3
LED Configuration1R1G1B
Physical Density360000pixel/m2
Scan method30 scanning
Refresh Rate≥2880HZ
Dirve ICMBI5153
Gray Scale14Bit
Cabinet size400mm*300mm
Module size200mm*100mm
brightness300-800cd/ m2
Color temperature5000K,6500K,9300K,12000K
View AngleHorizontal120°veritcal 120°
Best View Distance2m
Input voltageAC 220V/110V±10%
Working voltageDC4.2V
Maximum Power Consumption55W(300cd),80W(500cd), 100W(800cd)
Average Power Consumption30W(300cd),40W(500cd),50W(800cd)
Life time50000h
Working temperature-10℃ ~ 50℃
Net weight4.85Kg/pc



Application:
Outdoor fixed instalaation or rental Areas;Stage design(main screen,side screen,sky screen, floor screen); ,Exhibition,Concert,Events.

1) Excellent Quality,Pass ISO9001:2000
2) Low Power Comsuption, Energy Saving
3) High Brightness,Long Lifespan
4) Very Competitive Price, Good uniformity
5) Excellent Quality,Pass ISO9001:2000
6) High Reliability, Long Durability
7) Easy and fast installation
8) Timely Delivery
