960mm x 960mm RGB LED Video Display Panels with 1 / 4 Scan Constant Current Driving
960mm x 960mm RGB LED Video Display Panels with 1 / 4 Scan Constant Current Driving
960mm x 960mm RGB LED Video Display Panels with 1 / 4 Scan Constant Current Driving
960mm x 960mm RGB LED Video Display Panels with 1 / 4 Scan Constant Current Driving
Specifications
Brand Name :
Viao
Model Number :
P10 DIP RGB
Certification :
UL CE ROHS ISO ETL SGS SAA Fcc EMC
Place of Origin :
China
MOQ :
1 Square Meter
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union, Paypal, Credit Card, MoneyGram, VISA
Supply Ability :
6,000 square meters per month
Delivery Time :
4-6work days
Packaging Details :
Wooden box or Flight case
Brightness :
7000~10000 Nits, Indoor, Outdoor Use
Cabinet :
960x960mm, 1280x960mm, 960x800mm Etc
Resolution :
10000dots/m2
Tube Chip Color :
RGB Full Color Video
Power Consumption (max/avg) :
600/250 (W/sq.m.)
Maintenance :
Front Side And Rear Door
IP Rating (Front/Rear) :
IP65/IP43
Refresh Rate :
2000HZ-4500HZ
Module Size :
160X160mm, 320x160mm, 320x320mm Etc
Pixel Configuration :
1R1G1B
LED Chips Brand :
Cree / Nichia / Epistar / Nationstar
Description


Rgb video wall960mm x 960mm Outdoor Advertising Signs with 1 / 4 Scan Constant Current Driving

Product Description:

1. Using DIP technology make the screen have a excellent effect when it plays .

2. The cabinet become more firmed , and corrosion-resistant .

3 synchronization through the screen body color and brightness adjustment, screen body presents a delicate and vivid color performance;

4. high contrast, high refresh rate, making the LE display render the image without any delay, smear phenomenon;

5. compatible with a variety of signal source input, such as AV, S-Video, DVI, VGA, YPbPr, HDMI, SDI, DP, etc.;

6. Flightcase professional packaging protection, of the screen body control equipment has played a good protection;

7. Unique waterproof case designed to meet the IP65 protection standard, and can be directly installed in outdoor use.

Applications:

Mainly for outdoor advertising,information publishing,journalism and communication

in some places,such as cultural square,traffic arteries,stations,terminals,information

centers,entertainment venues,shopping centers,commercial city and etc.

Technical Specification:

Technical Parameter P10 Full Color
The optimum viewing distance 10m
The optimum viewing angle(Horizontal / Vertical ) 120 / 90
Maximum power consumption 900w/m2
Standard cabinet 960 *960mm
Resolution of cabinet 96 * 96
Weight of cabinet 50kg / m2
Driving method 1/4 scan constant current driving
Frame frequency ≥60hz/s
Refresh rate ≥ 200hz
Luminance of white balance ≥6500 CD/m2
Working environment temperature -30°C~55°C(-30 ~+65 optional)
Working voltage 220±10% or 110±10%
Grey scale/color Displaying colors1.07 billion(synchronized)
Brightness adjustment 256 levels of each color (R,G, B) can be adjusted manually, and 8 levels of each color can be adjusted automatically.
Input signal RF, S-Video, RGB, RGBHV, YUV, YC, Composition, etc.
Control system PCTV non-linear editing card + DVI display card + main controller card + optic fiber transmission(optional)
Average no failure time >5000 hours
Life-span >100000 hours
Malfunction dot rate <0.0001

960mm x 960mm RGB LED Video Display Panels with 1 / 4 Scan Constant Current Driving
