Specifications
Brand Name :
Viso
Model Number :
VS-G18inch
Certification :
UL CE ROHS ISO2000 ETL SGS SAA Fcc EMC
Place of Origin :
China
MOQ :
1 Unit or 1 PCS or 1 set Price
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union, Paypal, Credit Card, MoneyGram, VISA, MasterCard
Supply Ability :
50,000 units per month
Delivery Time :
3-5 work days
Packaging Details :
Carton box or Wooden case
UL CE ROHS ISO2000 ETL SGS SAA Fcc EMC :
88:88 , 8.88 9/10, 8.889, 8.888
Screen Dimension :
8inch 10inch 12inch 16inch 20inch 24inch Available
ED Tube Chip Color :
Red,Amber,Green,Blue,White
Service Access :
Rear Or Front Access
Master / Slave :
Single Side, Double Side
Operation :
RF, LCD Remote Control, TCP/IP
Voltage :
90~120V/220~240V
Waterproof :
IP68
Brightness :
8000nits
Description

Features:

1. Available in 4 and 5 digit formats
2. 100,000+ hour rated LEDs available from 8” to 24” tall
3. Multiple stroke digits for the ultimate brightness in daylight viewing
4. Wireless control standard (150 + feet of range)
5. 240 levels of automatic brightness control
6. Automatic daylight savings adjustments
7. Display Duration: 3-seconds to 9-seconds
8. Time displays in 12 and/or 24 hour format
8. Temperature displays in Fahrenheit and/or Celsius
9. Price displays to 99.99 in 4-digit display format
10. Price displays to 999.99 in 5-digit display format
11. Date displays in mm/dd format
12. Low profile 2.5" deep display housing

13. RF remote controller for the outdoor time and temp signs , the manual attached.

Technical Parameters:
Item Technical Parameters
Color Red, amber, green, blue or white
Digit height 4", 6", 8", 10", 12", 16", 18",20",24",27",32", 36", 40", 48", 60", 72" etc.
Digit design 4", 6", 8",10", 12", 16",18",20",24",27",32": standard digit.
Brightness control Auto-dimming by sensor or remote control.
Display Dimming Over 8 levels of automatic intensity adjustment.
Viewing Angle Indoor: H120° , V 100°, Outdoor: H 120° , V100° or customized.
Service Access Rear access or customized.
Master/Slave Single/Double/Three/four sides, use one control card, all working. or customized.
Casing Material Steel, aluminum available.
Front cover Displays with 32" & over digit high are without front cover; others with front cover.
Waterproof Level IP 65
Temperature sensor Default economical sensor, All sensor is available for more exact request.
LED Driving mode Constant current
Power Input 110/220VAC , 60Hz/50Hz
PC Communication Rs232
Communication Distance 8m
Remote control type 300ft / 100m, range of RF remote control.
Continuous Working Time Unlimited
Lifetime of LEDs >100,000 Hours
Installation Method Hanging, mounting or per custom design.
Working Temperature Indoor: -10°C ~ 40°C,Outdoor: -20°C ~ 60°C, Humidity: 15%~95%RH
Display format 88:88 or 88:88:88
GPS Optional
Product Parameters:
Digital Height Casing Material Casing Size (mm) Waterproof Level Typical Brightness Viewing Angle
6 inch Steel cabinet 729*228*100 N/A 100CD/sqm H:120°/ V:100°
8 inch Front cover 774*294*100 Frontside:IP65 1. 4000cd/sqm without front cover.
Rear service Backside:IP54 2. The brightness is lower adding
front cover but contrast degree
is higher, so clearer for outdoor
10 inch 1144*347*100 view.
12 inch 1384*400*100 3. With auto-dimmer.
16 inch 1122*507*100 4. With economical temperature
20 inch 1339*610*100 sensor.
24 inch 1339*610*100 1. With auto-dimmer.
27 inch 1939*788*100 2. With economical temperature
32 inch 2287*917*100 sensor.

Custom Size Large Outdoor LED Price Signs For Gas Stations With 4 And 5 Digit FormatsCustom Size Large Outdoor LED Price Signs For Gas Stations With 4 And 5 Digit Formats
