465W Bifacial Monocrystalline Silicon Panels For Environmental Conditions
465W Bifacial Monocrystalline Silicon Panels For Environmental Conditions
Specifications
Brand Name :
LS
Model Number :
NB465
Certification :
IEC 61215/IEC 61730/ISO 9001/ISO 14001/ISO 45001
Place of Origin :
China
MOQ :
800 pcs
Price :
consult prices online
Payment Terms :
T/T
Packaging Details :
Per Pallet: 31pcs(35mm)/36pcs(30mm) Per Container (40'HQ): 744pcs(35mm)/864pcs(30mm)
Power Range :
465W ~ 480W
Power Output Tolerance :
0W ~ +5W
Maximum Efficiency :
22.17%
Maximum Power Voltage (Vmp) :
34.84V ~ 35.48V (STC)
Maximum Power Current (Imp) :
13.35A ~ 13.53A (STC)
Open Circuit Voltage (Voc) :
41.47V ~ 42.07V (STC)
Short Circuit Current (Isc) :
14.43A ~ 14.61A (STC)
Module Efficiency :
21.48% ~ 22.17% (STC)
Description

465W Durable Bifacial Monocrystalline Silicon Panels for Various Environmental Conditions

465W Bifacial Monocrystalline Silicon Panels For Environmental Conditions

Product Description

The 182 N-TopCon Bifacial Module offers a power range from 465W to 480W, delivering maximum efficiency of 22.17%. With advanced N-TopCon technology, this bifacial module ensures high performance on both sides, effectively capturing more sunlight and boosting energy yield. Its sturdy anodized aluminum alloy frame and 2.0mm tempered glass make it highly durable, ideal for various environmental conditions.

Electrical Performance Parameters |STC
Model Type 465C(HBD)
60(182)		 470C(HBD)
60(182		 475C(HBD)
60(182		 480C(HBD)
60(182)
Nominal Max.Power Pmax(W) 465 470 475 480
Max.Power Voltage Vmp(V) 34.84 35.05 35.27 35.48
Max.Power Current Imp(A) 13.35 13.41 13.47 13.53
Open Circuit Voltage Voc(V) 41.47 41.67 41.87 42.07
ShortCircuit Current lsc(A) 14.43 14.49 14.55 14.61
Module Efficiency (%) 21.48 21.71 21.94 22.17
Power Output Tolerance (W) 0~+5W
*STC:Irradiance 1000W/m²,Cell Temperature 25℃,Air Mass AM1.5.
‘Power measurement tolerance ±3%.
Electrical Performance Parameters |NMOT
Model Type 465C(HBD)
60(182)		 470C(HBD)
60(182)		 475C(HBD)
60(182)		 480C(HBD)
60(182)
Nominal Max.Power Pmax(W) 349 353 357 361
Max.Power Voltage Vmp(V) 32.87 33.06 33.25 33.43
Max.Power Current Imp(A) 10.62 10.68 10.74 10.80
Open CircultVoltage Voc(V) 38.96 39.15 39.34 39.53
Short Circuit Current lsc(A) 11.74 11.79 11.84 11.89
·NMOT:Irradiance 800W/m²,Cell Temperature 20℃,Wind Speed 1m/s.
·Power measurement tolerance ±3%.
Structure Performance
Solar Cell Type 182mm N-TopConMono Cell (Half Cell)
Solar Cell Arrangement 120pcs(6×20)
Module Dimension 1909×1134×35mm/30mm
Weight 26.9kg(35mm)/25.7kg(30mm)
Front Glass 2.0mm,highly transparent tempered glass
with anti-reflective coating
Frame Anodized Aluminum Alloy
Junction Box IP68 rated
Cable 4mm²,portrait 200mm4(-0)0mm(+.landscape ((-
Length can be customized
Diode Quantity 3 pcs
Front side/Rear side 5400pa/2400pa
Connector MC4 Compatible
Per Pallet 31pcs(35mm)/36pcs(30mm)
Per Container(40'HQ) 744pcs(35mm)/864pcs(30mm)

Temperature Characteristics
Nominal Module Operating Temperature 44±2℃
Temperature Coefficient (Isc) +0.043%
Temperature Coefficient (Voc) -0.25%
Temperature Coefficient(Pmax) -0.30%

Maximum Parameters
Working Temperature -40~+85℃
Maximum System Voltage 1500V DC
Nominal Maximum Fuse Current 30A

Application

This module is best suited for large-scale solar power plants, commercial rooftops, and other installations where high efficiency and reliability are crucial. The bifacial design also makes it an excellent choice for areas with high reflectivity, such as snowy regions or surfaces near bodies of water, where both front and rear sides can contribute significantly to energy generation.

Shipping Methods

Supports global air and sea shipping.
