3 Ton- 4 Ton Yuejin small swing arm garbage truck 104 hp 2 axles
3 Ton- 4 Ton Yuejin small swing arm garbage truck 104 hp 2 axles
3 Ton- 4 Ton Yuejin small swing arm garbage truck 104 hp 2 axles
3 Ton- 4 Ton Yuejin small swing arm garbage truck 104 hp 2 axles
Specifications
Brand Name :
SUNY
Model Number :
SY1210BBLJ
Certification :
CCC, ASME, BV, SGS, etc
Place of Origin :
China
MOQ :
1 unit
Price :
USD 11,000~ 23.000 FOB Shanghai
Supply Ability :
1000 units per year
Packaging Details :
Ro-ro shipping / Bulk cargo shipping / Container shipping / SKD / CKD / etc
Garbage Container load :
3 Ton 4 Ton
Garbage Container shape :
aqusre shape, boat shap, bucket shape
Whole truck dimension :
5995 × 1990 × 2820 mm
Engine emission standard :
euro 2, euro 3, euro 4, euro 5
Truck chassis wheelbase :
3308mm
Garbage Container material :
side 3 mm, bottom 4mm
Chassi brand :
Yuejin
Chassis item :
NJ1042MDA3
Engine :
CA4DC2-10E3
Description

3 Ton- 4 Ton Yuejin small swing arm garbage truck 104 hp 2 axles

Description:

1,The large hydraulic cylinder drive the double arms, to install hydraulic legs to make sure the stability and safety of vehicle during operation.

2,the type of garbage box: sealed, semi-enclosed. The shape of garbage box: rectangular shape, trapezoidal.

3,The characterized of this vehicle: cargo compartment and vehicle body can be separated. One vehicle can work with more one garbage cargo body, recycling transport, improve the transport capacity, specially for short-distance transport, such as the sanitation department.

Competitive Advantage:

Steady quality

Competitive price

Best service

Specifications:

3 Ton- 4 Ton Yuejin small swing arm garbage truck 104 hp 2 axles

Vehicle Name:

Arm type garbage truck

Vehicle Category:

Special Purpose Vehicle

Engine

Engine Manufacturer

Displacement (ml)

Power (kw)

CA4DC2-10E3

FAW Dalian Diesel Engine Branch

3168

76

Dimensions:

5995 × 1990 × 2820 (mm)

Compartment Size :

× × (mm)

The total mass :

4495 (Kg)

Payload:

0

Curb weight:

3650 (Kg)

Rated Quality:

650 (Kg)

Approach / departure angle :

34/12 ()

Front / rear overhang :

1035/1652 (mm)

Axle load:

2023 / 2472

Wheelbase:

3308 (mm)

Number of axes:

2

Maximum speed:

90 (km / h)

Fuel consumption:

Spring:

11/ 10 +6

Number of tires :

6

Tire Size:

7.00-16,7.00 R16

Front track:

1628

Rear track:

1586

Yuejin truck chassis Specification

Chassis Type:

NJ1042MDA3

Chassis Category:

II

Product Name:

Truck chassis

Product Brand:

Yuejin brand

Zip Code:

210037

Catalog number :

44

Specifications:

Length: 5879 Width: 1880 Height: 2180

Steering Type :

Steering wheel

Number of axes:

2

Wheelbase:

3308

Spring:

11/ 10 +6

Number of tires :

6

Tire Size:

7.00-16,7.00 R16

Tread :

Front track 1628 Rear track 1586

The total mass :

4495

Curb weight:

2100

Quality Trailer :

Semitrailer saddle :

Front passenger :

3

Close to the departure angle:

34 / 18

Rear suspension :

1035 / 1536

Maximum speed:

90

Yuejin truck Engine Specification

Engine Model

Engine Manufacturer

Displacement (ML)

Power (ML)

CA4DC2-10E3

FAW Dalian Diesel Engine Branch

3168

76

3 Ton- 4 Ton Yuejin small swing arm garbage truck 104 hp 2 axles
