Foton Auman Water tank fire truck 14000 L -15000 L 4 X 2 drive , 200hp
Foton Auman Water tank fire truck 14000 L -15000 L 4 X 2 drive , 200hp
Foton Auman Water tank fire truck 14000 L -15000 L 4 X 2 drive , 200hp
Foton Auman Water tank fire truck 14000 L -15000 L 4 X 2 drive , 200hp
Foton Auman Water tank fire truck 14000 L -15000 L 4 X 2 drive , 200hp
Foton Auman Water tank fire truck 14000 L -15000 L 4 X 2 drive , 200hp
Foton Auman Water tank fire truck 14000 L -15000 L 4 X 2 drive , 200hp
Foton Auman Water tank fire truck 14000 L -15000 L 4 X 2 drive , 200hp
Specifications
Brand Name :
SUNY
Model Number :
SY5304SS
Certification :
CCC, ASME, BV, SGS, etc
Place of Origin :
China
MOQ :
1 unit
Price :
USD20000 /set- USD45000/set
Payment Terms :
Western Union, T/T, L/C
Supply Ability :
200 set per month
Delivery Time :
15-25 working days
Packaging Details :
Ro-ro sihpping / Bulk cargo shipping / Container shipping / SKD / CKD / etc
Chassis brand/ model :
foton / BJ5163ELFHD
Water tank capacity :
14000 L 15000L
Wheel base :
4500 mm
Dimension :
8300*2480*3000
Tank material :
Q235
Drive :
4 x 2
Engine :
YC6J200-42
G.V. W :
16000 kgs
Horse Power :
200 hp
Axles No. :
2
Function :
Water transport and sprinkle and fire fighting
Description

Foton Auman fire fighting truck, Water tank capacity 14000 L -15000 L 4 X 2 drive, 200hp

Description & application:

It can sprinkle the water to fight the fire. And contain and deliver the water.


Competitive Advantage:

1- Best service ----- we cherish each customer and opportunity. We will consider what the customer want.

2- Competitive price ----- based on same quality product, our price is most competitive

3- strict quality control ---- stable and good quality for each truck

Foton Auman fire fighting truck, Water tank capacity 14000 L -15000 L 4 X 2 drive, 200hp

Vehicle Description
Vehicle Type FOTON 4*2 water tank truck Overall dimensions(mm) 8300*2480*3000
GVW (kg) 16000 Mass in working order (kg) 6305
Loading capacity (kg) 9565 Max speed (Km/h) 90
Chassis Description
Chassis Model BJ5163ELFHD
Allowable Passengers In Cab 2,3 Air conditioner optional
Wheel base(mm) 4500 Number of axles 2
F/R track base(mm) 1883/1847 F/R overhang(mm) 1365/2435
Approach/Departure angle(°) 22/1 Spring plate 10/10+8
F/R axle-load 6000/10000 Type of fuel diesel
Tire specification 9.00R20 Tire quantity +1
Traction system 4*2 Operation control system Steering wheel
Braking system Air braking Electric system 24v
Engine Description
Engine model YC6J200-42 Engine Manufacturer Guangxi Yuchai Machinery Co., LTD
Exhaust/output 6500 Horse power 200
Up-parts Description
Fact cubage(L) 14000-15000
Tank Dimensions(mm) 5000*2100*1350
Tank Description

1. Shape: oval

2. Material:carbon steel

3.Thickness；4mm

All water truck can be make water wagon for transporting drinking water.
Standard Equipment

Equipped with front,rear, side sprinkler (sprinkling width＞14m )

Equipped with rear working platform with water cannon which can be turned all-round (range＞28m),can be adjusted into flinging, heavy rain,light rain,drizzle model, with security barrier.

Equipped with Hangzhou Weilong pump(suction lift＞6m)

Equipped with fire valve, water valve, and filter gauze
Optional Equipment Shower ,pneumatic valve,Honda pump,tool box
Production cycle 15-20 days
Warranty 12 month, from the date of supply
Foton Auman Water tank fire truck 14000 L -15000 L 4 X 2 drive , 200hp
Foton Auman Water tank fire truck 14000 L -15000 L 4 X 2 drive , 200hp
