2 Axle 40ft Shipping Container Trailer Light Weight For Transport Logistics System
2 Axle 40ft Shipping Container Trailer Light Weight For Transport Logistics System
2 Axle 40ft Shipping Container Trailer Light Weight For Transport Logistics System
2 Axle 40ft Shipping Container Trailer Light Weight For Transport Logistics System
2 Axle 40ft Shipping Container Trailer Light Weight For Transport Logistics System
2 Axle 40ft Shipping Container Trailer Light Weight For Transport Logistics System
2 Axle 40ft Shipping Container Trailer Light Weight For Transport Logistics System
2 Axle 40ft Shipping Container Trailer Light Weight For Transport Logistics System
Specifications
Brand Name :
Huilong
Model Number :
Cargo Container Trailer
Certification :
ISO9001
Place of Origin :
Suizhou, China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
200 units per month
Delivery Time :
4~6 weeks
Packaging Details :
in nude or by wax
Amount of Axle :
2
Payload :
35000KGS
Floor :
3mm checker plate
Twist Lock :
12 no. of ISO Twist Lock
Welding :
Submerged Arc Welding
Landing Gear :
FUWA brand Two-speed
Description

2 Axle Cargo Container Trailer 40FT Shipping Container Trailer Light Weight

Description:

Main application

Skeleton container trailer is a kind of semi-trailer frame for container transportation. Mainly used in shipyard, port, route, highway, transfer station, bridge, tunnel, multi-modal transport logistics system.

Advantages:

• Quickly stevedoring

It can be quickly loaded and unloaded, and can be directly and conveniently transferred from one conveyance to another.

• Meeting needs

It is convenient for cargo loading and unloading, and meets the individual needs of customers. The skeletal trailer made by Huilong factory has stable quality, reliable performance.

• Paint

One coat of rust proof paint, two coats of paint

• Testing

We will test the quality of the trailer before delivery

Specifications:

DIMENSIONS
Tare Weight 4800KGS Payload 35000KGS
Overall Length 12400mm Overall Width 2480mm
Technical Data
Chassis

Heavy duty and extra durability designed I beam;

Opting for high tensile steel Q345B,

welded by automatic Submerged-Arc processes.

Top Flange 14mm,width 140mm;

Middle Flange 6mm,height 500mm;

Bottom Flange 16mm,width 140mm.
Axle 2 axles
Brand name: FUWA
Suspension

Mechanical suspension with 10pcs leaf spring
Spring Leaf spring
King Pin

FUWA brand 2” Bolt-in King Pin
Landing Gear

FUWA brand Two-speed, manual operating, heavy duty landing gear
Wheel Rim

9.0-22.5 steel wheel rim
Twist Lock

12nos. of ISO twist lock for 1x20ft container, 2x20ft container, 1x40ft container
Tyre

12R22.5 tire, 8PCS
Spare Tyre One set of spare tire including a carrier
Braking System

WABCO RE 4 relay valve; T30/30 Spring brake chamber; 45L air tanks
Painting

Complete Chassis sand blasting to clean rust;

1 coat of anticorrosive prime, 2 coats of final paint
Accessories

One standard tool box, one spare tyre carrier
Gallery
2 Axle 40ft Shipping Container Trailer Light Weight For Transport Logistics System
