316L Milk Transport Truck , Stainless Steel Water Tank Trailer With Pump System
316L Milk Transport Truck , Stainless Steel Water Tank Trailer With Pump System
Specifications
Brand Name :
Huilong
Model Number :
Milk Tank Trailer
Certification :
ISO9001
Place of Origin :
Suizhou, China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
200 units per month
Packaging Details :
in nude or by wax
Container Volume :
316L
Body Material :
Stainless Steel
Support Legs Load :
28T
Spare Tire Carriers :
2 pieces
King Pin Size :
3.5"
Tire Config :
12R22.5 Vacuum Tire
Description

316L Milk Transport Truck , Stainless Steel Water Tank Trailer With Pump System

Description:

• Core Application

Fresh milk tank trailer is the non-dangerous goods vehicle and facilitates the milk transportation between the pasture and the dairy plant. The tank of the trailer ideally matches with the characteristics of the milk: liquid, precipitation, deterioration. More importantly, the chemical reaction with the milk is preventive. The valid volume is 316L.

• Automatic Pumping and Cleaning

The milk trailer is equipped with pump and washing system, which can clean the tank automatically. The efficiency of manual washing is improved.

Advantages:

• Flexible Compartment

One or more compartments can be designed in accordance with actual demand.

• Dust Prevention

The reliable breather valve can prevent the dust and decrease material loss.

• Alloy Steel Axle

The axle produced by high-quality alloy steel has a high bending resistance and strong capacity.

• Food Hygiene

The inner liner made of stainless steel achieves the highest hygienic standard. The automatic welding and refined polishing make the interior evener and firmer.

• Built-in Anti-Wave Board

The anti-wave plate is designed in arc structure. The R50 arc can optimize the transition fillet and can keep the tank clean and tidy without any omission.

Specifications:

Tare Weight 8000kg--14000kg
Volume 316L
Axle Weight Load 13T/16T
Axle Brand FUWA/BPW/others
Suspension Common mechanical or Air Suspension
King Pin JOST 3.5" traction pin
Dimensions 10500-13000mm*2500mm*3800mm
Support Legs JOST Single 28T heavy duty
Wheel Rim 9.0-20
Wheelbase 1310mm
Steel Spring 10 pieces per axle
Ladder Mechanical ladder
Accessories 1 Set standard tool box
Light Tail lamp with turn signal, brake light & reflector, side lamp etc.
Painting 1 coat of anticorrosive prime, twice coats of final paint
Tire Spec. 12R22.5 Vacuum tire
Number of Tire 8/12 pieces
Spare Tire Carriers 2 pieces
Manhole Cover 500mm manhole cover; 2 sets with 2 breather valve
Discharge Valve & Pipe 4 inch disc valve & 4 inch seamless steel tube
Brake Chamber 4 big chamber
Brake System Dual Line Brake system
Configuration
316L Milk Transport Truck , Stainless Steel Water Tank Trailer With Pump System
