V Shape Pneumatic Tanker Trailer Inner Anti - Corrosion Small Discharge Loss
V Shape Pneumatic Tanker Trailer Inner Anti - Corrosion Small Discharge Loss
V Shape Pneumatic Tanker Trailer Inner Anti - Corrosion Small Discharge Loss
V Shape Pneumatic Tanker Trailer Inner Anti - Corrosion Small Discharge Loss
V Shape Pneumatic Tanker Trailer Inner Anti - Corrosion Small Discharge Loss
V Shape Pneumatic Tanker Trailer Inner Anti - Corrosion Small Discharge Loss
Specifications
Brand Name :
Huilong
Model Number :
Dry Bulk Trailer
Certification :
ISO9001
Place of Origin :
Suizhou, China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
200 units per month
Delivery Time :
4~6 weeks
Packaging Details :
in nude or by wax
Container Shape :
V Shape
Amount of Axle :
3
Vessel Body :
Q235A/6mm steel sheet
Body Volume :
60 tons
Tire Config :
11.00R20, 12.00R20, 11R22.5, 12R22.5, 315/80R22.5 for option
Color :
Red
Description

V Shape Pneumatic Tanker Trailer Inner Anti - Corrosion Small Discharge Loss

Description:

• Core Application

V shape dry bulk tank trailer fits for bulk transportation of building materials, metal powder, coal combustion products etc. Usually, it finishes transportation tasks assigned by building enterprises.

• V Shape

This product is configured with three axes. The V shape of the tank structure has a lot of notable characteristics: low gravity center, superior balance, fast loading and unloading etc.

• Long Life Cycle

The anti-corrosion coating on the inner wall and anti-rust paint on the outer wall perfectly protects the tank. Thus, the life cycle of the tank is prolonged.

Advantages:

• Quality Assurance

The quality of the trailer is on the basis of the durable steel plate, firm welding technology, and strict quality evaluation.

• Small Discharge Loss

Our trailer is equipped with a fluidized belt inside that can be used with an air compressor to efficiently unload powder with a small amount of residue. Accordingly, cement loss can be diminished.

• Protect the Quality of Cement

Special containers are adopted during transportation and storage. It is not easy to get wet and cement can be stored for a long time without deterioration.

Specifications:

Overall Size 12500mm x 2500mm x 3800mm
Capacity 60 tons
Tank Body Q235A/6mm steel sheet
End Plate Q235A/6mm ball shape
Axle 13T/16T capacity, FUWA / BPW Brand
Suspension Mechanical suspension or air suspension
Leaf Spring Leaf spring or air bag
Floor Checkered plate
Tire 11.00R20, 12.00R20, 11R22.5, 12R22.5, 315/80R22.5 for option
Wheel Rim Optional range: 8.5-20, 9.0-20, 8.25-22.5, 9.0-22.5 steel wheel rim
Discharge Pipe 4" seamless steel tube
Engine Diesel engine or electrical motor
Air Compressor 37Kw, 0.2Mpa.1000r/min
Kingpin 2’’/3.5’’ bolt-in king pin
Landing Gear JOST brand two-speed, manual operating, heavy duty landing gear
Air-charging System 2 main hole, 2check valve, 1.5" safe valve, 0.4Mpa guage
Outlet Discharge Pipe 4" rubber hose 6m
Braking System WABCO RE6 relay valve; T30/30 spring brake chamber; 40L air tanks
Painting

Complete chassis sand blasting to clean rust;

1 coat of anti-corrosive prime;

2 coat of final paint
Accessories One standard tool box
