Specifications
Brand Name :
AFS
Model Number :
300kg/h line
Certification :
CE
Place of Origin :
China
MOQ :
1set
Price :
$8000-10000/set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000pcs/m
Delivery Time :
10-15days
Packaging Details :
non fumigation export standard wooden case
Material :
SUS201
Capacity :
200-300kg/h
Air compressor :
22kw
Garlic :
Dry
Shipping :
EXW,FOB,CNF,CIF
Warranty :
One Year
Description

Garlic Peeling Machines, Garlic Processing Machines, Small Garlic Peeling Line 200-300kg/H

Garlic Peeling Machines, Garlic Processing Machines, Small Garlic Peeling Line 200-300kg/H

garlic peeling process :
garlic elevator---garlic bulb into cloves machine---garlic elevator---garlic peeling machine---garlic picking conveyor

The garlic peeling machine connect with air compressor, to remove the garlic skin, no damage to garlic, high quality. Material use Stainless steel 201.

Specification:

Machine name Specification

Garlic elevator

Voltage:380v,50hz

Power:0.55kw

Dimension:2000*500*1550mm

Weight:180kg

Speed : fixed

Garlic bulb into cloves machine

Voltage: 380v,50hz

Power:1.87kw

Dimension:1260*600*1180mm

Weight :138kg

Garlic elevator

Voltage:380v,50hz

Power:0.55kw

Dimension:2000*500*1550mm

Weight:180kg

Speed : fixed

Garlic peeling machine

Capacity:200-300kg/h

Input voltage:380v,50hz

Total power:1.1kw

Air compressor :22kw screw air compressor

air pressure:8kg/cm3

Dimension :1500*630*1370mm

Weight :240kg

Air compressor

22kw,match with garlic peeling machine

Dimension : 1100*800*1300mm

Weight :300kg

Air storage tank : 2070*830*920mm

Weight :180kg

Garlic picking conveyor

The picking conveyor mainly used to pick up garlics that didn’t peeled, then can put into peeling machine and peel again.

Voltage:220v,50hz

Power:90w

Dimension:3000*585*600mm

Weight:90kg
