CCC Certified IP40 Metal Shell DC12V Din Rail Ethernet Switch 10 Port
CCC Certified IP40 Metal Shell DC12V Din Rail Ethernet Switch 10 Port
CCC Certified IP40 Metal Shell DC12V Din Rail Ethernet Switch 10 Port
CCC Certified IP40 Metal Shell DC12V Din Rail Ethernet Switch 10 Port
CCC Certified IP40 Metal Shell DC12V Din Rail Ethernet Switch 10 Port
CCC Certified IP40 Metal Shell DC12V Din Rail Ethernet Switch 10 Port
CCC Certified IP40 Metal Shell DC12V Din Rail Ethernet Switch 10 Port
CCC Certified IP40 Metal Shell DC12V Din Rail Ethernet Switch 10 Port
CCC Certified IP40 Metal Shell DC12V Din Rail Ethernet Switch 10 Port
CCC Certified IP40 Metal Shell DC12V Din Rail Ethernet Switch 10 Port
CCC Certified IP40 Metal Shell DC12V Din Rail Ethernet Switch 10 Port
CCC Certified IP40 Metal Shell DC12V Din Rail Ethernet Switch 10 Port
Specifications
Brand Name :
Hioso
Model Number :
Foway 4510PFS
Certification :
CE, RoHS, CCC
Place of Origin :
China, Guang dong
MOQ :
1
Price :
Negotiable
Payment Terms :
TT
Supply Ability :
4000pcs/month
Delivery Time :
2-12 working days
Packaging Details :
38X24X18 CM
Item :
Din Rail Switch
Support :
Two wide voltage
Backplane bandwidth :
22G
Mac address :
16K
Working :
-10℃~60℃
Storage :
-40℃～85℃
Description

10 Port Din Rail Ethernet Switch 8 1000M PoE + 2 1000M SFP Ports Poe Switch

Character

  • 10 / 100 / 1000M adaptive RJ45 ports, with MDI and MDI-X auto recognition functions
  • Support 1000M SFP port, maximum transmission distance 120km

  • Provide two wide voltage 10 ~ 60 VDC input; provide reverse connection protection

  • Support up to 10kbyte ultra long frame packet transmission, 22G backplane bandwidth

  • Each RJ45 electric port is added with anti high voltage circuit to improve the ability of lightning protection and anti high voltage interference

  • With a strong IP40 metal shell and supports rail or wall mounting

Technical Specification

Parameter Specification
Transmission 10/100/1000Mbps
Port

8 RJ45 ports: 10/100/1000M

2 1000M Combo: 1Gbps
Conversion mode Medium conversion, storing and forwarding/straight-through
MAC address table 16K
Buffer space 2Mbit
Flow control Full duplex state: flow control; half-duplex state: back pressure mode
Delay 1us
Bit error rate <1/1000000000
MTBF 100,000 hours
LED FX Link (fiber link/action), TP1/2/3/4/5/67/8 100M/1000M (twisted pair rate) , TP1/2/3/4/5/6/7/8 Link (twisted pair link/action);P1 (power supply P1 connected) ,P2(power supply P2 connected),SYS (system)
Power 12/24/48 VDC,18 ~ 30VAC input
Power consumption 6.5W
Installation Din rail installation, wall mounting installation
Dimensions 135mm×52mm×105mm (height * width * depth)

CCC Certified IP40 Metal Shell DC12V Din Rail Ethernet Switch 10 Port

CCC Certified IP40 Metal Shell DC12V Din Rail Ethernet Switch 10 Port
